Chapter 1
Using a Visionscape® Smart Camera for the First Time
"Setting Up Network Communications" in the Visionscape® Smart Camera
HE1600T Guide.
Note: When using a Visionscape
environment, it MUST be programmed to use a static IP address instead of
DHCP. This is to prevent loss of communications due to IP lease renewal by the
DHCP server.
Follow these steps when connecting the Visionscape
for the first time:
Connect the Visionscape
1.
the PC that will be running the FrontRunner™ software.
Apply power to the Visionscape
2.
this AFTER making the physical connection to the network.
Start the FrontRunner™ application by selecting Start > Visionscape >
3.
Visionscape FrontRunner. The main FrontRunner™ screen is displayed,
as shown in Figure 1–1.
FIGURE 1–1.
Select View > Network Overview to display the Network Overview
4.
window, as shown in Figure 1–2.
1-2
®
FrontRunner™ Main Screen
Getting Started With Visionscape® Smart Camera
®
Smart Camera HE1600T in a production
®
Smart Camera HE1600T
Smart Camera HE1600T to the same network as
®
Smart Camera HE1600T; be sure to do
Device Buttons
Device Bar
Toolbar
