General Information
The AVR cooling air inlet includes a filter. Verify the filter
is installed and properly seated at time the unit is
installed.

The Generator

A
A. Lock with Cover
B. Main Line Circuit
Breaker (Generator
Disconnect)
C. Control Panel
D. Battery Compartment
(Battery not supplied)
E. Data Plate Location
6
E
F
S
R
Q
P
Figure 2-1. Components and Control Locations
F. Oil Dipstick
G. Exhaust Enclosure
H. Status LED Indicators
J. Oil Fill Cap
K. Oil Filter
Check the filter at regular maintenance intervals to verify
proper airflow.
B
C G
D
M
N
L
O
L. Oil Drain Hose
M. Composite Base
N. Airbox with Air Cleaner
O. Automatic Voltage
Regulator (AVR)
P. Sediment Trap
Owner's Manual for 60 Hz Synergy™ Generators
K
J
Q. Fuel Regulator
R. Fuel Inlet
S. AVR Air Filter
H
A
003589
