Maintenance

Preparing for Maintenance

DANGER
Automatic start-up. Disconnect utility power and
render unit inoperable before working on unit.
Failure to do so will result in death or serious injury.
Before performing any maintenance, proceed as follows
to prevent the generator from accidental startup:
1. Turn the generator off and allow the engine to cool.
Verify that the unit is OFF.
2. With the generator shut down, lift the lid and
remove the front panel.
3. Remove the 7.5 amp fuse from the control panel.
4. Remove the intake side panel. (See
Panel Removal.)
5. See Figure 4-1. Disconnect the white battery
charger cable.
Figure 4-1. Disconnecting Battery Charger Cable
24
(000191)
Intake Side
002389
