Keysight CX3322A Quick Operation Manual

Cx3300 series device current waveform analyzer 2-channel model 4-channel model
Hide thumbs Also See for CX3322A:
Table of Contents

Advertisement

Quick Links

Download this manual
Keysight Technologies CX3300 Series
Device Current Waveform Analyzer
CX3322A 2-Channel Model
CX3324A 4-Channel Model
Quick Operation
Guide

Advertisement

Table of Contents
loading

Related Manuals for Keysight CX3322A

Summary of Contents for Keysight CX3322A

  • Page 1 Keysight Technologies CX3300 Series Device Current Waveform Analyzer CX3322A 2-Channel Model CX3324A 4-Channel Model Quick Operation Guide...

  • Page 2: Warranty

    Declarations of Conformity for this prod- providers of commercial computer soft- if not correctly performed or adhered uct and for other Keysight products may ware pursuant to the FAR and the DFARS to, could result in damage to the be downloaded from the Web. Go to and are set forth specifically in writing product or loss of important data.
  • Page 3 Contents File • How to save the data • How to load the data • What types of data formats are supported on the CX3300 ? • How to save rarely occurring waveforms automatically Setup • How to change the horizontal scale and position •...
  • Page 4 Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to save the waveform data How to save the Waveform data in CSV format. Waveform Channel 1 How to save the Waveform FFT data in CSV format. Waveform “Spectrum- Magnitude” or “Spectrum- Phase”...
  • Page 5 How to save the Window Image data (Format : PNG / JPEG / Bitmap). Screen Capture PNG or JPEG or Bitmap How to save all setting data and waveform data (File Type : Composite). Composite Note: For further details about the File Type and Format, please refer to “What types of data formats are supported on the CX3300 ?”.
  • Page 6 Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to load the data Select one of folders to access SelectedFile.cxwav In this case, select Waveform File (*.cxwav). Note: For further details about the File Type and Format, please refer to “What types of data formats are supported on the CX3300?”.
  • Page 7 Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide What types of data formats are supported on the CX3300 ? The CX3300 supports several File Types and Formats when the setup data or the waveform data is saved or loaded.

  • Page 8: How To Save Rarely Occurring Waveforms Automatically

    Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to save rarely occurring waveforms automatically "Auto Save" can be used to automatically save a current waveform if it satisfies specific conditions. Select “Utilities > Configuration > Auto Save”. Change Limit Count...
  • Page 9 Push the “Auto Save” ( red circle ) button on the lower left of the display. The waveforms consistent with the trigger condition are stored up until the Limit Count set on the “Configuration > Auto Save” window. This number is counted up until the Limit Count. The 5 files are created in this sample.

  • Page 10: How To Change The Horizontal Scale And Position

    Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to change the horizontal scale and position You can change the horizontal scale and position using any of the following methods: Using the knobs on the Horizontal Controls Using the Horizontal mini dialog box Using the X Axis dialog box for fine control.
  • Page 11 Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to change the sampling rate Click on the Horizontal summary to open the Horizontal mini dialog box. Un-check “Automatic”. Set the “Sampling Rate”. Note: If “Auto” is enabled, a suitable sampling rate is selected automatically by the...

  • Page 12: How To Change The Memory Depth

    Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to change the memory depth Click on “Horizontal summary” to open the “Timebase” mini dialog box. Click on the “ ” at the upper right of the mini dialog box to open the Setting dialog box.

  • Page 13: How To Change The 14-Bit Or 16-Bit Resolution

    Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to change the 14-bit or 16-bit resolution. Change a 14-bit (high speed mode) or a 16-bit (high resolution mode) using the [High Reso] key. Indicator on Horizontal Summary (none) : 14-bit (high speed mode) “HR”...
  • Page 14 Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to change the vertical scale and position How to select the channel. Select the target waveform by either: Pressing [1], [2], [3] or [4] for the analog input channels Clicking on the icons on the Waveform tray for the analog input channels or function waveform.
  • Page 15 How to Change the horizontal scale and position You can change the horizontal scale and position using any of the following methods: Using the knobs on Vertical Controls Using the Vertical mini dialog box Using the Y Axis dialog box for fine control. Double-Click Vertical control keys Channel summary...
  • Page 16 Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to change the current range Click on the Channel summary to open the Channel mini dialog box. Un-check “Auto”. Select the “Range”. Click Note: If “Auto” is enabled, a suitable range is selected automatically by the vertical scale setting controlled by the Vertical scale control knob.

  • Page 17: How To Set The Bandwidth Limit

    Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to set the bandwidth limit Click on the Channel summary to open the Channel mini dialog box. Click on the “ ” at the upper right of the window to open the Setting dialog box.

  • Page 18: How To Minimize The Offset Current

    Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to minimize the offset current Perform “User Calibration”. The offset current of the current sensor will be minimized. Perform a actual measurement and fix the connection and the CX3300 settings such as the Mainframe current range.
  • Page 19 3-2. Null measurement Click on the Channel summary to open the Channel mini dialog box. Turn “ON” the Null measurement. Press “Measure”. The Null offset is automatically subtracted from the waveform Click The Null indicator turned on. Restore the connection then make an actual measurement again. Note: The Null offset is set to zero when: The current sensor is disconnected...
  • Page 20 Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to perform a Skew adjustment The skew between the channels on the measurement device can be adjusted. Preparation 1-1. Connect the Current Sensor (CX1101A/CX1102A/CX1103A) or the Passive Probe Interface Adapter (CX1151A) to the device.

  • Page 21: What Determines The Effective Bandwidth Of The Instrument

    Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide What determines the effective bandwidth of the instrument? The effective bandwidth of the instrument is determined by the following settings and displayed in each “Channel summary” on the front panel. Summary bar...
  • Page 22 Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to zoom in on the waveform The CX3300 has two kinds of zoom in functions: a. Zoom at single display b. “Anywhere” Zoom. Zoom at single display a-1. Click on the “Move” icon to change the ‘Zoom” icon.
  • Page 23 Tips: By using the Scale Reference function, you can change the base point of the Zoom. - Utilities > Configuration > User Preference > Scale Reference Utilities [ Scale Reference > Horizontal Sample ] [ “0 s” selected ] Stretch around 0 s 4 ms 0.
  • Page 24 b. “Anywhere” Zoom b-1. Click on the “Waveforms” icon. b-2. Click on the "1 & zoom" icon. b-3. Drag the boundary line of the area. Move Drag Tips: You can also specify the scale and position on the Axis dialog. Double-Click Double-Click...
  • Page 25 Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to use the waveform memory Click on the “Analysis” icon to open the “Analysis” dialog box. Select “Waveform Memories”. Select “ON”. Select “Memory X” ( X is a number. X=1 in this case. ) Press [Load].

  • Page 26: How To Overlay Multiple Acquisitions

    Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to overlay multiple acquisitions ON : Display > Persistence > Infinity 1-1. Click the “Display” icon on the Tool Palette. 1-2. Select “Persistence” on the Display tool palette. 1-3. Drag and drop the “Infinity” icon on the Display tool palette onto the area of interest on the waveform.
  • Page 27 OFF : Display > Persistence > Normal 2-1. Click the “Display” icon on the Tool Palette. 2-2. Select “Persistence” on the Display tool palette. 2-3. Drag and drop the “Normal” icon on the Display tool palette onto the area of interest on the waveform. Infinity Normal...
  • Page 28 Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to display the secondary Y axis Select “Axis” in the Display Tool Pallet. Then, drag and drop the “X1, Y1 and Y2” icon on the waveform. axis axis...
  • Page 29 How to delete the secondary Y Axis. There are 2 ways to delete the secondary Y Axis. 2-1. Drag and drop the “Display > Axis > X1 and Y 1” icon. 2-2. Double-click somewhere on the screen and switch OFF the “Secondary Y Axis”...
  • Page 30 Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to set the Trigger Press [Sweep] to set the Trigger to ON. Select the Trigger Type. ( Default: “Edge” ) 2-1. Select “Trigger” on the Tool Palette 2-2. Select the Trigger Type ( “Edge” in this case ) from the Trigger Tool Palette 2-3.
  • Page 31 Change the trigger source, slope and level using either: The Trigger Controls The Trigger Mini dialog box. For more detailed conditions, open the “Setting > Trigger dialog box” by either: Pressing the [Menu] button Clicking the “ ” at the upper right of the Trigger mini dialog box. Trigger Controls Trigger Summary...

  • Page 32: How To Apply A Measurement Function

    Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to apply a Measurement Function Apply a Measurement Function (“+width” in this case) 1-1. Click the “Measurement” icon on the Tool Palette. 1-2. Drag and drop the “+width” icon onto the target. The color of the icon shows the target waveform.
  • Page 33 For more detailed conditions, open the Measurements pane by clicking the Setting icon on the Measurement Stats window and change the settings. Double-click the Measurements menu Click the Measurement 1 menu Click You can also access the Measurement pane via Side Bar > Analysis > Measurement.
  • Page 34 Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to apply the A-B marker Turn the Marker ON. 1-1. Click “Display” on the Tool Palette. 1-2. Click “Markers”. 1-3. Drag and drop the A-B marker icon onto the target. The color of the icon shows the target waveform.
  • Page 35 For more detailed conditions, open the Markers dialog box by clicking the Setting icon on the Marker Results window and change the settings. Click Turn the Marker OFF. 3-1. Click “Display” on the Tool Palette. 3-2. Click “Markers”. 3-3. Drag and drop the OFF icon onto the target.

  • Page 36: How To Place Pointers On Waveforms

    Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to place pointers on waveforms Select “Markers” in the Display Tool Pallet. Then, drag and drop the “Cross” icon on the point that you want to monitor. You can monitor multiple points...
  • Page 37 How to delete the Cross Hair Marker. There are 3 ways to delete the cross hair marker. 2-1. Right-click the mouse on the cross hair marker and choose “Delete”. Choose “Delete”. 2-2. Click the gear icon on the upper right corner of the main screen. Display options ( ON / OFF ) Delete the marker by “x”...
  • Page 38 2-3. Click the gear icon on the upper right corner of the “Marker” screen. Delete all markers by “x” or “Delete All” button. Display options ( ON / OFF ) Delete the marker by “x” click...
  • Page 39 Tips : - You can select whether or not the cross hair marker is tracked as follows: Right-click the mouse on the cross hair marker. This cross hair marker can be tracked on the waveform in this mode. Choose “Track”. This cross hair marker can NOT be tracked on the waveform in this mode.
  • Page 40 Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to add an Annotation Drag and drop the Display icon onto the target waveform. 1-1. Click the “Display” icon on the Tool Palette. 1-2. Click the “Annotations” tab. 1-3. Drag and drop the “Display” icon on the Display tool palette onto the target waveform.
  • Page 41 How to edit the Annotation 2-1. Select Edit by right clicking on “No text”. 2-2. You can edit the Annotation. Edit How to delete the Annotation You can delete the Annotation by right clicking on it, as shown with “Ch1” in the example below, and selecting Delete.

  • Page 42: How To Apply The Post-Filter

    Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to apply the post-filter How to apply the post-filter 1-1. Click the “Function” icon on the Tool Palette. 1-2. Select “Filter” on the Function tool palette. 1-3. Drag and drop the “Smooth 100pts” icon on the Function tool palette onto the area of interest on the waveform.
  • Page 43 How to change the settings 2-1. Click on the “Analysis” icon to open the Analysis dialog box. 2-2. Select “Function 1”. 2-3. You can change the Smoothing Points.
  • Page 44 Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to perform the FFT ( Fast Fourier Transform ) How to apply the FFT 1-1. Click the “Analysis” icon on the Tool Palette. 1-2. Drag and drop the “Spectrum” icon on the Analysis tool palette onto the chosen area of interest on the waveform.
  • Page 45 How to change the FFT settings ? 2-1. Double-click anywhere on the horizontal axes in the Spectrum graph view. 2-2. Un-check the “Auto” box. 2-3. Click this button until the Scale is 100.0KHz. Spectrum graph How to adjust the chosen area of interest on the waveform ? The CX3300 has two ways in which to adjust the chosen area of interest.
  • Page 46 Gating Function > FFT Gating Horizontal Move Waveform Zoom > FFT Adjust this area. Note: The result of the FFT is changed in real time by adjusting the chosen area of interest on the waveform.
  • Page 47 Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to analyze the waveform in the specified area with an Area marker There are four types of Area markers as follows; Area, Area (+width), Area (-width) and Area (period). Using the mouse drag and drop option, the Area marker allows you to freely change the area range.
  • Page 48 Click and hold the mouse button, and horizontally drag the Start or Stop line over the specified area of interest. Horizontal Drag Area Infinity Baseline Mean : The average current Stop Start from Start to Stop [ Apply the “Area (+width), Area (-width), Area (period) marker” ] Apply the “Area (+width) marker For example, as with the Area marker, drag and drop the “Area (+width)”...
  • Page 49 The result of applying the "Area (+ width), Area (-width), Area (period) marker" The area is automatically determined according to where you drop the marker. Area (+width) Area (-width) Area (period)
  • Page 50 Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to apply the Power and Current Profiler Drag and drop the Display icon onto the target waveform. 1-1. Click the “Analysis” icon on the Tool Palette. 1-2. Drag and drop the “Profiler” icon on the Analysis tool palette onto the chosen area on the waveform.
  • Page 51 Perform the Auto Profile (Optional) The Auto Profile function can be used to help divide the segments into levels to view the vertical level difference. You can also manually adjust the levels of the segments. 2-1. Click the “Auto Profile” button to open the Auto Profile window. 2-2.
  • Page 52 Perform Auto Profile (Continued) 2-3. Click the “Perform” button.
  • Page 53 Adjust the position of the line of the segments manually. Select “Zoom”. 2. Select the area to zoom using the mouse. Select “Profile”. Drag New Drag and drop Reset zoom...
  • Page 54 Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to apply the XY analysis How to apply the XY analysis 1-1. Click the “Analysis” icon on the Tool Palette. 1-2. Drag and drop the “XY” icon on the Analysis tool palette on the channel set as Source1.
  • Page 55 How to change the target channels 2-1. Double-click “X1” icon in the XY graph view. 2-2. Set the target channel as Source1 and Source2 on the XY1 window. XY graph How to adjust the scale of the graph 3-1. Double-click anywhere on the horizontal or vertical axes in the XY graph view.
  • Page 56 How to adjust a specific area on the waveform. 4-1. Select “Gating” from “All/View/Gating” at the top left on the XY graph. 4-2. The result of the XY graph is changed in real time by adjusting the specified area on the waveform. Adjust this area.
  • Page 57 Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to change the measurement units (Clone to Ampere Hour) in Area analysis Select “Markers” in the Display Tool Pallet, then drag and drop the “Area” icon on the interest area on the waveform.
  • Page 58 Select “Utilities > Configuration > User Preference” window. Change “C” to “Ah”. Utilities The measurement unit is changed from “C” to “Ah”. Note: - The setting is also retained in CX3300 power cycle and [Default Setup]. - It returns to the factory condition with [Factory Default] 1.

  • Page 59: How To Perform User Calibration

    Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to perform User calibration User calibration is effective for making more accurate measurements by allowing you to perform error corrections of measurement data. Before starting the user calibration, connect the CX1100 to the CX3300 analog input channel.
  • Page 60 How to perform User calibration ? 2-1. Click on the “Utilities” icon to open the Utilities menu. 2-2. Click “Configuration” to open the “Configuration” dialog box. 2-3. Click “User Calibration” to display the “Configuration>User Calibration” screen. 2-4. Select the “Gain/Offset” or “Offset” radio button for the channel under user calibration.

  • Page 61: How To Check The Firmware Revisions

    Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to check the firmware revisions Click on the "About Device Current Waveform Analyzer" icon. The “About CX3300 Device Current Waveform Analyzer” window will open. The Firmware revisions are displayed. About the Device Current Waveform Analyzer...
  • Page 62 Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to simulate the 50 MHz or 100 MHz bandwidth option on the mainframe with the 200 MHz option. The mainframe has three maximum bandwidth options, 50 MHz, 100 MHz and 200 MHz.
  • Page 63 Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide Where to find the Online help Click the “Help” icon on the Side Bar. Click the “On-line Help (.chm)” button to open the online help.
  • Page 64 Keysight Technologies CX3300 Current Waveform Analyzer Quick Operation Guide How to display the menu bar There are two ways to display the menu bar. Hover the mouse arrow over the upper edge of the monitor. Click the blue bar at the top of the monitor, or click any other area.
  • Page 66 This information is subject to change without notice. © Keysight Technologies 2018 Edition 1, June 2018 *CX3300-90300* CX3300-90300 www.keysight.com...
