Summary of Contents for Monoprice Blackbird 9140A-PCA
- Page 1 Blackbird™ 6G-SDI to HDMI® Converter P/N 21829 User's Manual...
-
Page 2: Safety Warnings And Guidelines
SAFETY WARNINGS AND GUIDELINES Please read this entire manual before using this device, paying extra attention to these safety warnings and guidelines. Please keep this manual in a safe place for future reference. This device is intended for indoor use only. ... - Page 3 Take care to prevent damage to the power cord. Do not allow it to become crimped, pinched, walked on, or become tangled with other cords. Ensure that the power cord does not present a tripping hazard. Remove the batteries from the controller if it will go unused for a lengthy period of time.
-
Page 4: Customer Service
If you have any problem with your order, please give us an opportunity to make it right. You can contact a Monoprice Customer Service representative through the Live Chat link on our website www.monoprice.com during normal business hours (Mon-Fri: 5am-7pm PT, Sat-Sun: 9am-... - Page 5 Rear Panel 1. DC 12V: DC barrel connector for connecting the included AC power adapter. 2. POWER LED: The LED illuminates red when power is applied. 3. SDI IN 1: BNC connector for connecting an SDI video source. 4. SDI IN 2: BNC connector for connecting an SDI video source. 5.
- Page 6 Top Panel AUDIO 1. AUDIO: Press the AUDIO button to cycle through the audio options. See the BUTTON section for details. 2. VOLUME: Press the up or down VOLUME buttons to increase or decrease the output volume level. The LEDs to the left of the buttons indicate the volume level. 3.
-
Page 7: Sample Connection Diagram
SAMPLE CONNECTION DIAGRAM INSTALLATION Perform the following steps to install the 6G-SDI to HDMI® converter. 1. Ensure that all equipment to be connected is powered off and unplugged from its power source. 2. Place or mount the converter in its intended location. 3. -
Page 8: Dip Switches
6. (Optional) Using a 6G-SDI cable (not included), plug one end into the SDI IN 2 connector on the converter, then plug the other end into the output of a second SDI source device. 7. (Optional) Using an audio cable with a 3.5mm mono TS jack on one end, plug one end into the L-ANALOG jack on the converter, then plug the other end into the left channel input of an external audio device. -
Page 9: Audio Button
11 and 12 13 and 14 15 and 16 Button Lock DIP switch 6 controls the button lock status. Place DIP switch 6 in the OFF position to UNLOCK the top panel buttons or put it in the ON position to LOCK the top panel buttons. -
Page 10: Specifications
SPECIFICATIONS Model 21829 Video Inputs 2x SDI Video Outputs 1x HDMI®, 1x SDI SD-SDI (SMPTE 259M) HD-SDI (SMPTE 292M) Supported SDI Standards 3G-SDI (SMPTE 424M) 6G-SDI (SMPTE ST-2081) Maximum Input Resolution 4K@30Hz 4:4:4 RGB 8-bit Maximum SDI Output Resolution 4K@30Hz 4:4:4 RGB 8-bit Maximum HDMI Output Resolution 4K@30Hz 8-bit HDMI Version... -
Page 11: Technical Support
TECHNICAL SUPPORT Monoprice is pleased to provide free, live, online technical support to assist you with any questions you may have about installation, setup, troubleshooting, or product recommendations. If you ever need assistance with your new product, please come online to talk to one of our friendly and knowledgeable Tech Support Associates.
