Summary of Contents for Monoprice 21828
- Page 1 Blackbird™ 4K HDMI® to 6G SDI Converter P/N 21828 User's Manual...
-
Page 2: Safety Warnings And Guidelines
SAFETY WARNINGS AND GUIDELINES Please read this entire manual before using this device, paying extra attention to these safety warnings and guidelines. Please keep this manual in a safe place for future reference. This device is intended for indoor use only. ... - Page 3 Take care to prevent damage to the power cord. Do not allow it to become crimped, pinched, walked on, or become tangled with other cords. Ensure that the power cord does not present a tripping hazard. Remove the batteries from the controller if it will go unused for a lengthy period of time.
-
Page 4: Customer Service
If you have any problem with your order, please give us an opportunity to make it right. You can contact a Monoprice Customer Service representative through the Live Chat link on our website www.monoprice.com during normal business hours (Mon-Fri: 5am-7pm PT, Sat-Sun: 9am-... -
Page 5: Product Overview
PRODUCT OVERVIEW Front Panel 1. HDMI IN: HDMI® port for connecting the HDMI video source device. 2. AUDIO LED: The LED illuminates blue when external audio is selected as the audio source. 3. L - ANALOG or AES/EBU: 3.5mm jack for connecting left channel analog audio or AES/EBU digital audio. - Page 6 Side Panel 1. DIP SWITCHES: 8 DIP switches to control the EDID settings, locking or unlocking the top panel buttons, and enabling or disabling external audio. The DIP switch is ON (1) when it is in the down position and OFF (0) when it is in the up position. See the SWITCHES section for details.
-
Page 7: Sample Connection Diagram
2. VOLUME: Press the up or down VOLUME buttons to increase or decrease the input volume level. The LEDs to the left of the buttons indicate the volume level. 3. MUTE: Press the MUTE button to enable or disable audio muting. SAMPLE CONNECTION DIAGRAM... -
Page 8: Dip Switches
DIP SWITCHES EDID DIP switches 1 and 2 are used to set the EDID. Switch 1 Switch 2 EDID Setting AUTO: The converter automatically selects the best video resolution of the HDMI® input, up to 4K@30Hz 4:4:4. FORCE UHD: The converter forces the input resolution to 4K@30Hz 4:2:2. -
Page 9: Audio Button
Stereo analog audio is selected TECHNICAL SUPPORT Monoprice is pleased to provide free, live, online technical support to assist you with any questions you may have about installation, setup, troubleshooting, or product recommendations. If you ever need assistance with your new product, please come online to talk to one of our friendly and knowledgeable Tech Support Associates. -
Page 10: Specifications
4.7" x 3.9" x 1.2" (120 x 100 x 30 mm) Weight 7.1 oz. (200 g) Blackbird™ is a trademark of Monoprice Inc. HDMI®, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
