Summary of Contents for Monoprice 10318
- Page 1 3G-SDI to HDMI® Converter P/N 10318 User's Manual...
-
Page 2: Safety Warnings And Guidelines
SAFETY WARNINGS AND GUIDELINES Please read this entire manual before using this device, paying extra attention to these safety warnings and guidelines. Please keep this manual in a safe place for future reference. This device is intended for indoor use only. ... - Page 3 Take care to prevent damage to the power cord. Do not allow it to become crimped, pinched, walked on, or become tangled with other cords. Ensure that the power cord does not present a tripping hazard. Never unplug the unit by pulling on the power cord. Always ...
- Page 4 FEATURES Supports SD-SDI, HD-SDI, and 3G-SDI video inputs Outputs HDMI® video at resolutions up to 1080p@60Hz Includes an SDI output with re-clock functionality Supports 8-bit, 10-bit, and 12-bit per channel Deep Color Supports the RGB, YCbCr 4:4:4, and YCbCr 4:2:2 color spaces ...
-
Page 5: Customer Service
CUSTOMER SERVICE The Monoprice Customer Service department is dedicated to ensuring that your ordering, purchasing, and delivery experience is second to none. If you have any problem with your order, please give us an opportunity to make it right. You can contact a Monoprice Customer Service representative through the Live Chat link on our website www.monoprice.com during normal business... -
Page 6: Product Overview
PRODUCT OVERVIEW SDI In: BNC connector for connecting the SDI video source device using a 75 ohm RG-59 cable (not included). SDI Out: BNC connector for connecting an SDI video output device using a 75 ohm RG-59 cable (not included). The output is re- clocked, allowing multiple converters to be cascaded. -
Page 7: Sample Connection Diagram
SAMPLE CONNECTION DIAGRAM INSTALLATION Ensure that all devices to be connected are powered off and disconnected from their power source. 2. Place or mount the converter in its desired location. Using a High Speed HDMI® Cable (not included), plug one end into the HDMI video input on your HDMI display, then plug the other end into the HDMI Out connector on the converter. -
Page 8: Specifications
Congratulations, you have successfully installed your new 3G-SDI to HDMI converter! SPECIFICATIONS Model 10318 Inputs 1x SDI BNC female 1x SDI BNC female, 1x HDMI® Outputs female Supported SDI Standards... - Page 9 SD-SDI: up to 984 feet (300 Maximum SDI Transmission meters) Distance (over RG-59 coaxial HD-SDI: up to 426 feet (130 cable) meters) Supports Color Spaces RGB, YCbCr 4:4:4, YCbCr 4:2:2 Up to 8 channels at 48k Audio Support sampling rate Input Power 5 VDC, 2A AC Adapter Input Power...
