Introduction

The Iris+ is a wireless personal attack system ideal for use in all types of nancial, industrial and
commercial premises, where sta need the security of a personal attack alarm with total
mobility. The use of the latest techniques in design with the extensive use of surface mount
technology and microprocessors makes Iris+ a highly reliable, exible and user friendly system.
With most of the systems features under software control, Iris+ can easily be con gured to
meet a speci c customers requirements. Communication with the user is via a Liquid Crystal
Display (LCD), which shows the system status at all times.
Capable of identifying 256 individual transmitters, extensive event and historic logs, Personal
Identi cation Number (PIN) access and antenna tamper are just a few of the features o ered by
Iris+. The wide range of features and facilities incorporated into Iris+ are normally only found in
full alarm control equipment, making Iris+ unique in wireless personal attack systems and a
leader in the eld.
The Iris+ system consists of a single xed receiver unit, the required number of transmitter
units and ancillary equipment dependant upon application. The Iris+ receiver is installed
within a rigid casing and mounted at a predetermined location, while the transmitters can be
installed into portable push-button Units, xed money clip units or xed contact operated
units. In addition the Iris+ will accept up to eight hard wired inputs via an input module.
Note: Regular users of the Iris system will notice that the latest version of Iris+ comes with the
added bene ts of a re ned PCB layout and all software features unlocked as standard. The Iris+
industry renowned ease of operation and functionality remain exactly the same.
Tools & test equipment
No special test equipment is needed when installing the receiver. Only standard hand tools are
required to install and commission the system.
