Technical Speci cations

Physical
Environmental
Operating frequency
RF sensitivity
Supply
Inputs
Outputs
Standards
Dimensions H 195mm x W 296mm x D 110mm
Weight 4 kg
Temperature -10 to +55 degrees C
Humidity Up to 75% non-condensing
458.5 to 458.8 MHz
channel spacing 25khz (MPT 1329)
-120 dBm for 12 dB sinad NBFM radio strength
indication dynamic range of 60 dB AFC capture and
hold +/- 3 KHz
Voltage 10 to 16Vdc
Max current 250mA @ 12Vdc (with back light activated)
Up to 256 wireless transmitters
Up to 8 hardwired inputs
4 programmable relay outputs
30V 28VA (1amp max) contacts
RS485 bus port
RS232 port
Complies with BS4737 intruder alarm systems
BS7042 high security intruder alarm systems
BS6799 (up to class 5) wire free intruder alarm
systems
EN50131 class 2 grade 2
MPT1329 WT licence exempt
BS8243 (when used in conjunction with BS8243
compliant wireless transmitters)
