Relay output con guration

Available events that can be used to make the Iris+ relay outputs operate are as follows:
NOTHING
GROUP: HUA ALARM*
GROUP: HUA LOCAL*
GROUP: DISPLAY*
GROUP: FAULT*
*
GROUP: LOG
GROUP: TAMPER*
GROUP: RECORD*
GROUP: ALARM*
GROUP: LOCAL*
GROUP: NETWORK*
EVENT: IRIS TO CLEAR
EVENT: IRIS TO RESET
EVENT: ARMING THE SYSTEM
EVENT: IRIS TO TEST
EVENT: TXER GROUP 1 ON
EVENT: TXER GROUP 2 ON
EVENT: TXER GROUP 3 ON
EVENT: TXER GROUP 4 ON
EVENT: TXER GROUP 5 ON
EVENT: TXER GROUP 6 ON
EVENT: TXER GROUP 7 ON
EVENT: TXER GROUP 8 ON
EVENT: TXER GROUP 9 ON
EVENT: TXER GROUP 10 ON
EVENT: TXER GROUP 11 ON
EVENT: TXER GROUP 12 ON
EVENT: TXER GROUP 13 ON
EVENT: TXER GROUP 14 ON
EVENT: TXER GROUP 15 ON
EVENT: TXER GROUP 16 ON
EVENT: ALARM
EVENT: MEDITILT ALARM
EVENT: CONTACT ALARM
EVENT: CALL IN FAIL
EVENT: ALARM STAGE 1 ON
EVENT: ALARM STAGE 1 OFF
EVENT: ALARM STAGE 2 ON
EVENT: ALARM STAGE 2 OFF
EVENT: PERSONNEL CALL
* Note: Multiple 'GROUP:' type events can be assigned to a relay output
No action to be taken
Raid alarm transmissions
Raid local alert transmissions
Events to be displayed, not logged
Equipment failiure/malfunctions
Events to be logged when in clear
Tamper events
Events to be recorded (logged) at all times
General alarms transmissions
General local transmissions
Events sent over a network link
Events considered to be clear transmissions
Iris control keyswitch in the 'reset' position
Iris control keyswitch in the 'clear' position
Iris control keyswitch in the 'test' position
Transmitter group 1 is active
Transmitter group 2 is active
Transmitter group 3 is active
Transmitter group 4 is active
Transmitter group 5 is active
Transmitter group 6 is active
Transmitter group 7 is active
Transmitter group 8 is active
Transmitter group 9 is active
Transmitter group 10 is active
Transmitter group 11 is active
Transmitter group 12 is active
Transmitter group 13 is active
Transmitter group 14 is active
Transmitter group 15 is active
Transmitter group 16 is active
Alarm from an alarm transmitter
Alarm transmitter has been in man down position for 45 seconds
Alarm transmission from a contact operated transmitter
Transmitter has failed to call in to the Iris system
An active stage 1 alarm condition
Stage 1 alarm conditon has cleared
An active stage 2 alarm condition
Stage 2 alarm conditon has cleared
Alarm transmission from a personnel call transmitter
Page 25 of 32
(as used in the previous section)
