MeiTrack MS02 User Manual

Hide thumbs Also See for MS02:
Table of Contents

Advertisement

Quick Links

Download this manual
MEITRACK MS02 User Guide
MEITRACK MS02 User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS02 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MeiTrack MS02

Summary of Contents for MeiTrack MS02

  • Page 1 MEITRACK MS02 User Guide MEITRACK MS02 User Guide...

  • Page 2: Change History

    File Name MEITRACK MS02 User Guide Created By Renny Lee Project GPS Tracking System Creation Date 2010-05-25 Update Date 2014-09-23 Subproject MS02 Total Pages Version V2.9 Confidential External Documentation Copyright © 2014 Meitrack Group All rights reserved. - 2 -...

  • Page 3: Table Of Contents

    3.1 Configuring GPRS Parameters .............................- 5 - 3.1.1 Configured By Using Software ..........................- 5 - 3.1.2 Configured By Running SMS Commands........................- 7 - 3.2 Logging In to the MS02 ...............................- 8 - 3.3 Adding a Device ..................................- 9 - 3.4 Checking Status Updates ..............................- 11 - 4 Software Functions ..................................- 11 -...
  • Page 4 4.6 Status Bar ..................................- 46 - 4.6.1 Status ..................................- 46 - 4.6.2 Alarm ..................................- 46 - 4.6.3 Uploading a Report ..............................- 46 - 5 MS02 Mobile Phone Version ...............................- 47 - Copyright © 2014 Meitrack Group All rights reserved. - 4 -...

  • Page 5: Copyright And Disclaimer

    The MS02, Meitrack GPS Tracking System, is a server-based online positioning tracking platform. The MS02 can monitor people, articles, and vehicles installed with trackers in real time on web pages. This facilitates remote management. The MS02 can view, remotely control, analyze, and collect statistics on historical data.
  • Page 6 IP: Set the active server IP address. The Meitrack server IP address is 67.203.13.26.  Port: Set the TCP or IP port for receiving GPRS data. The Meitrack server port is 8800.  Secondary IP and Port: This feature is available for users with multiple servers. When the active server fails, device data will be sent to the standby server automatically.

  • Page 7: Configured By Running Sms Commands

    Set a command for the tracker (GPRS) ID. W000000,010,S/N Check the S/N on the device. The S/N is the unique identification code for the device on MS02. It cannot be changed. For example, if the S/N is 4037828853, the command is as follows: W000000,010,4037828853 Set a command for the APN.

  • Page 8: Logging In To The Ms02

    Example: 0000,A12,6,0 3.2 Logging In to the MS02 Log in to the MS02 in any of the following ways:  Visit ms02.trackingmate.com through your PC. Obtain a user name and password when you purchase an account.

  • Page 9: Adding A Device

    Obtain a user name and password when you purchase an account. 3.3 Adding a Device Log in to the system, and choose Manage > Admin. Click the user name. The following page is displayed: Copyright © 2014 Meitrack Group All rights reserved. - 9 -...
  • Page 10 For the GT30i, GT60, VT300, VT310, and VT400, the default password is 000000. For the MT90, MVT100, MVT340, MVT380, MVT600, MVT800, and T1, the default password is 0000. If the password is changed, enter the latest one. Copyright © 2014 Meitrack Group All rights reserved. - 10 -...

  • Page 11: Checking Status Updates

    4.1 System 4.1.1 Language Choose System > Language. The MS02 supports 24 languages. The MS02 system language changes according to Window languages. For example, if the Chinese Windows system is running, the default MS02 system language is Chinese. 4.1.2 Skin Choose System >...

  • Page 12: Management

    For details about how to add a device, see section 3.3. 4.2.1.2 Adding an Existing Device Choose Manage > Admin > User Name > Add Existing Device. Multiple accounts can be used to monitor the same device. Copyright © 2014 Meitrack Group All rights reserved. - 12 -...
  • Page 13 Password: indicates the password for sending SMS commands. For the GT30, GT60, VT300, VT310, and VT400, the default password is 000000. For the MT90, MVT100, MVT340, MVT380, MVT600, MVT800, and T1, the default password is 0000. If the password is changed, enter the latest one. Copyright © 2014 Meitrack Group All rights reserved. - 13 -...

  • Page 14: Removing A Device

    4.2.2 Tracker Customization Choose Manage > Tracker customer define to customize alarms, I/O status, and the connected sensor formula. The function is only available for devices bounded to the MS02. Copyright © 2014 Meitrack Group All rights reserved. - 14 -...

  • Page 15: Customizing An Alarm

    For example, select a device, and set Alarm Type to SOS Pressed and Name to SOS. When the customized alarm triggers, device status will be displayed on a map, as shown in the following figure. Copyright © 2014 Meitrack Group All rights reserved. - 15 -...

  • Page 16: Customizing Status

    Output 1 connects the engine circuit to a relay. When the circuit is cut off (output activated), cut is defined. If the circuit is connected (output inactivated), normal is defined. To customize status, click , specify parameters shown in the following figure, and click Add. Copyright © 2014 Meitrack Group All rights reserved. - 16 -...

  • Page 17: Customize A Sensor

    4.2.3 Customizing a Temperature Sensor The function is only available for the MVT600, T1, and MVT800. A temperature sensor is used to measure temperature of vehicles and environments in real time. Copyright © 2014 Meitrack Group All rights reserved. - 17 -...

  • Page 18: Setting A Fuel Sensor

    MEITRACK MS02 User Guide For details, see the MEITRACK Temperature Sensor User Guide. 4.2.4 Setting a Fuel Sensor The function is only available for the MVT600, T1, and MVT800. A fuel sensor is used to measure vehicle fuel and check whether an alarm is generated.

  • Page 19: Setting A Led

    MEITRACK MS02 User Guide For details, see the MEITRACK Fuel Sensor User Guide. 4.2.5 Setting a LED The function is only available for the MVT600, and T1. An LED is used to issue vehicle advertisements and emergent notices. Copyright © 2014 Meitrack Group All rights reserved.

  • Page 20: Setting Parameters

    MEITRACK MS02 User Guide For details, see the MEITRACK LED User Guide. 4.2.6 Setting Parameters The function is only available for the MVT100 and TC68S. Set parameters for an online device. Copyright © 2014 Meitrack Group All rights reserved. - 20 -...

  • Page 21: Geo-Fence

    A geo-fence includes tracker geo-fence settings and binding, which must be used together. Tracker Geo-fence Settings: Draw a geo-fence as required. Tracker Geo-fence Binding: Bind the geo-fence to a device. Copyright © 2014 Meitrack Group All rights reserved. - 21 -...
  • Page 22 Circle/Polygon: A geo-fence can be circular and polygonal. Draw a geo-fence: Circle: Select Circle, and click . The map page is displayed. Click the map, and drag the mouse to define the circle semidiameter. Copyright © 2014 Meitrack Group All rights reserved. - 22 -...
  • Page 23 32 sides. Enter and save the geo-fence name. The geo-fence can work after the geo-fence is bound to a device. Tracker Geo-fence Binding: Bind the geo-fence to a device. Copyright © 2014 Meitrack Group All rights reserved. - 23 -...
  • Page 24 Device Name: Select a device to be bounded. Alarm Property: Select an alarm rule. Select exist: Select a geo-fence from the drop-down list. Click to check the geo-fence location. Copyright © 2014 Meitrack Group All rights reserved. - 24 -...

  • Page 25: Rfid Functions

    1. Choose Manage > Manage Driver Information to add driver information. 2. Choose Manage > Manage RFID to create a RFID, and bind the RFID to a driver name. Copyright © 2014 Meitrack Group All rights reserved. - 25 -...

  • Page 26: Online Upgrade

    MEITRACK MS02 User Guide Note: To manage RFIDs, driver information must be added first. RFIDs can be authorized. For details, see the MEITRACK RFID User Guide. 4.2.9 Online Upgrade The function is only available for the MT90, MVT100, MVT600, MVT800, and T1.

  • Page 27: Querying A Report

    MEITRACK MS02 User Guide For details, see the OTA User Guide. 4.3 Querying a Report 4.3.1 Alarm Report Choose Reports > Alarm Report. The alarm report page is displayed. Copyright © 2014 Meitrack Group All rights reserved. - 27 -...

  • Page 28: Search Criteria

    : Export data in a KML file. 2. Display an alarm point on the map. Double-click an alarm. The alarm point together with the alarm type will be displayed on the map. Copyright © 2014 Meitrack Group All rights reserved. - 28 -...

  • Page 29: Historical Data Report

    You can query historical data in the same way as the alarm report. : Display historical routes. : Select the check box to filter the same address while displaying the route. The route with directions will be displayed on the map. Copyright © 2014 Meitrack Group All rights reserved. - 29 -...

  • Page 30: Speed Report (Pie Chart)

    Switch to the start point. Slow down the playback. Play or stop Speed up the playback. Switch to the end point. 4.3.3 Speed Report (Pie Chart) Choose Reports > Speed Report (Pie Chart). Copyright © 2014 Meitrack Group All rights reserved. - 30 -...

  • Page 31: Speed Report (Line Chart)

    Choose Reports > Speed Report (Line Chart), specify the device name, start time, and end time, and click . The line chart will display the speed trend. The function helps learn drivers' driving habits and monitor drivers' speed. Copyright © 2014 Meitrack Group All rights reserved. - 31 -...

  • Page 32: Parking Report

    Get Address: If the Get Address check box is selected, addresses will be displayed. One IP address can be used to parse a maximum of 2,500 addresses one day. 4.3.6 Distance Report Choose Reports > Distance Report. Copyright © 2014 Meitrack Group All rights reserved. - 32 -...

  • Page 33: Distance Statistics Report

    10 km/h for over 3 minutes, the device stops moving. 4.3.7 Distance Statistics Report Choose Reports > Distance Statistics Report. The report collects statistics on vehicle mileages in a specific time period. Copyright © 2014 Meitrack Group All rights reserved. - 33 -...

  • Page 34: Sensor Report

    The report can display fuel in graph after a formula is customized (see 3.2.2.3). For example, select a device (fuel sensor), set the start time and end time, and click . The fuel changes are displayed, as shown in the following figure. Copyright © 2014 Meitrack Group All rights reserved. - 34 -...

  • Page 35: Sensor Average Value Report

    Choose Reports > Platform Message. With the function, you can query information sent from the MS02 platform to the A21 sensor or from the A21 sensor to the MS02 platform. Currently, A21 can be connected to MVT600 or T1 only.

  • Page 36: Input Status Report

    Choose Reports > Input Status Change Report. 4.3.12 Vehicle Driver RFID Report Choose Reports > Vehicle Driver RFID Report. The report is used to record driver attendance. Only MVT600 and T1 support RFID currently. Copyright © 2014 Meitrack Group All rights reserved. - 36 -...

  • Page 37: Photo Report

    The function is only available for the MVT600 and T1. Choose Reports > Picture Report. Select a device, and specify the start time and end time to view photos. Only the MVT600 and T1 support photographing. Copyright © 2014 Meitrack Group All rights reserved. - 37 -...

  • Page 38: Vehicle Maintenance

    The function is only available for the TC68S. Set the function in any of the following two ways: 1. Set by Meitrack Manager.The maintenance data is synchronized between the platform and the device after the device is online. 2. Set by the MS02.

  • Page 39: Query

    Click to set the maintenance reminder. The reminder can be set only when the device is online. 4.4 Query 4.4.1 Querying a Location Choose Search > Manual Location Search. Copyright © 2014 Meitrack Group All rights reserved. - 39 -...

  • Page 40: Querying A Path

    The Get Directions window is displayed. Enter the start point and destination, and click Search. The route will be displayed on the map. A is the start point, and B is the destination. Copyright © 2014 Meitrack Group All rights reserved. - 40 -...

  • Page 41: Poi

    The function is used to mark points of interest (POIs). 4.4.3.1 Querying a POI Query a POI that is added. Enter the POI name, and click . The result is displayed. Copyright © 2014 Meitrack Group All rights reserved. - 41 -...

  • Page 42: Adding A Poi

    A dialog box is displayed, indicating that data is updated successfully. The POI will be displayed on the map. 4.4.3.3 Editing a POI Select a POI to be edited, and click Copyright © 2014 Meitrack Group All rights reserved. - 42 -...

  • Page 43: Deleting A Poi

    4.4.3.7 Displaying All POIs Select Show all POI when map opens to display all POIs. The setting will affect forever. 4.4.3.8 Exporting POIs Click to export POIs to an Excel file. Copyright © 2014 Meitrack Group All rights reserved. - 43 -...

  • Page 44: Control Panel

    Deselect all devices. : Save selected items. You can group the selected items and name the group. : Enter a group name, and load the items in the group. Copyright © 2014 Meitrack Group All rights reserved. - 44 -...

  • Page 45: Device List

    Transmission progress: indicates the data transmission progress. When you send a GPRS command, the progress is displayed, such as Sending, Received, and Not Online. Retry: If a GPRS command fails to be sent, click to send the command again. 4.5.2 Sending a Command Copyright © 2014 Meitrack Group All rights reserved. - 45 -...

  • Page 46: Status Bar

    Send Command: Select the check box of a device, and click Send Command to send a command to the device by GPRS. For details about command formats, see related product user guides. Note: The MS02 can automatically detect the user time zone. Do not change the GPRS time zone, and remain default time zone 0. Otherwise, data may not be synchronized completely.

  • Page 47: Ms02 Mobile Phone Version

    The function is only available for iOS and Android. Website: http://m.ms02.trackingmate.com/. The user ID and password are the same as that of the MS02 computer system version. Enter the user ID and password, and click Logon. The home page is displayed, as shown in the following figure.
  • Page 48 1. Map: Vehicle locations can be displayed on the map in real time. 2. Device: Vehicle details, including the received time, latitude, longitude, speed, direction, altitude, and customized data, can be queried. Copyright © 2014 Meitrack Group All rights reserved. - 48 -...
  • Page 49 Edit: Edit device information, such as the device name, password, model, and SIM card. 3. Command: Send a command by GPRS. 4. Settings: Set parameters shown in the following figure, and log out of the MS02. Copyright © 2014 Meitrack Group All rights reserved.
  • Page 50 MEITRACK MS02 User Guide If you have any questions, do not hesitate to email us at info@meitrack.com. Copyright © 2014 Meitrack Group All rights reserved. - 50 -...
