Topeak PrepStation Pro User Manual page 2

DuoSpoke Wrench
13G Shimano®
(3.5mm) (4.3mm)
DuoSpoke Wrench (13G/ 4.3 mm)
Art no. TPS-SP13
14G 15G
(3.4mm) (3.2mm)
DuoSpoke Wrench (14G/ 15G)
Art no. TPS-SP14
Mavic® Mavic®
M7 M9
DuoSpoke Wrench (M7/ M9)
Art no. TPS-SP15
Threadless Saw Guide
Preset
Option 1
1
1.2mm Saw
Guide Spacer
2mm Saw
1.2mm Saw
Guide Spacer
Guide Spacer
4mm Allen Key
2 3
Sprocket Clean Brush Chainring Nut Wrench
Art no. TPS-SP33
PREPSTATION PRO - TOOLS
Cable & Housing Cutter
Art no. TPS-SP13-15
PowerLink Pliers
OPERATION OF POWERLINK PLIERS
1
4
Art no. TPS-SP26
Option 2
For Carbon Saw Blade
Threadless Nut Setter
2mm Saw
Guide Spacer
4
Half Round Rasp
Art no. TPS-SP31
8/10mm Double Open End Spanner
Art no. TPS-SP11
7mm Spanner
Half Round Rasp
* Campagnolo® is a registered trademark of Campagnolo S.r.I.
* Teflon® is a registered trademark of DuPont.
OPERATION OF CABLE & HOUSING CUTTER
A.
B.
2 3
5
USING THREADLESS NUT SETTER
Rubber Mallet
Art no. TPS-SP32
• Star nut not included
Rubber Mallet Rubber Mallet
Art no. TPS-SP27
Art no. TPS-SP43
Adjustable Spanner
Art no. TPS-SP31
* Mavic® is a registered trademark of SALOMON S.A.
* Torx® is a registered trademark of the Camcar Corp. division of Textron Inds.
* Shimano® is a registered trademark of Shimano® Inc. * Octalink® is a registered trademark of Shimano Inc.
All Speeds Chain Tool
Art no. TPS-SP16
Fits multi-speed chains, including Campagnolo® 11 speed.
Primary Chain Secondary
Use Primary Chain
Link Fence Chain Link Fence
Link Fence to
install or remove
chain pin. Use
Secondary Chain
Link Fence to
loosen stiff links.
1. Chain Pin Breaker
2
2. Rivet Anvil of Hollow Pin
3. Chain Hook
1
3
Art no. TPS-SP12
WARNING
1. When pressing in the chain
pin, push down on the top of
the chain to keep it fully
engaged in the chain tool
cradle. Make sure the press
pin of the chain tool is
centered against the chain
pin.
2. Inspect chain rivet again and
be sure chain links can bend
freely after replacement.
MAINTENANCE
1. Lubricate and maintain tool with Teflon® based lubricant when needed.
Art no. TPS-SP25 2 To prevent rusting, keep tool dry.
.
INSTALLATION INSTRUCTION FOR CAMPAGNOLO® 11-SPEED HOLLOW CHAIN PIN
After pressing the special replacement pin into Campagnolo® 11-Speed chain and breaking off the
guide portion, the break off end of the chain rivet is required to be peened to prevent chain failure.
1
Chain Hook & Wear Indicator
CHAIN WEAR INDICATOR
Art no. TPS-SP32 Art no. TPS-SP32
1) Put "STEP 1" inside chain space and fully engage a roller
CHAIN HOOK
Art no. TPS-SP36
Copyright © Topeak, Inc. 2014
User's Guide
GB
Art no. TPS-SP41
HOW TO REPLACE CHAIN PIN
1
Target chain rivet
Use Chain Hook to hook chain and hold
the target chain rivet in center position.
2
Press out old chain pin and
replace with new chain pin.
3
Snap off new chain pin guide.
Press chain
pin as little
as possible
to loosen
the stiff link.
2
Before
After
3/4 Turn
Art no. TPS-SP09
2) PRESS "STEP 2" on a roller
" STEP 2 " can't engage a roller
Chain in good condition
" STEP 2 " can fully engage a roller Chain replacement
required
