Topeak PREPSTAND ZX User Manual

MAXIMUM
WEIGHT CAPACITY
25 kg / 55 lb
Not Compatible With Aero
Seatpost Width Larger
Than 45mm.
SETTING PREPSTAND™ ZX
Raise the Bike Holder Arm to release it.
Raise
Fully extend the Support Legs and lock
the Lower Quick Release Clamp Lever.
1
2
NOTE:
Always fully
expand support
legs for a steady
foundation.
PREPSTAND
Bike Holder Arm
Upper Quick Release
Clamp Lever
Support Legs
Unfold the Bike Holder Arm
as shown.
Adjust the height of the Bike Holder Arm to
the proper position by releasing the Upper
Quick Release Clamp Lever.
NOTE: Do not extend
Bike Holder Arm past
zero (0) on the scale.
ZX
™
Optional Tool Tray
(Art no. TW016-SP01)
Lower Quick Release
Clamp Lever
Lower the Bike Holder Arm firmly.
Lower
2
1
USER'S GUIDE
DO NOT use on gravel,
uneven or soft surfaces.
Check the stability of
the PREPSTAND™ ZX
periodically to ensure
secure portage of your
bike.
Avoid bodily harm when
folding Bike Holder Arm.
WARRANTY
2-year Warranty: All mechanical components against manufacturing defects only.
Warranty Claim Requirements
To obtain warranty service, you must have your original sales receipt. Items
returned without a sales receipt will assume that the warranty begins on the
date of manufacture. All warranties will be void if the product is damaged due
to user crash, abuse, system alteration, modification, or used in any way not
intended as described in this manual.
* The specifications and design are subject to change without notice.
Please contact your Topeak dealer with any questions.
For USA customer service call: 1-800-250-3068
www.topeak.com
Release Support Legs by opening
the Lower Quick Release Clamp
Lever.
Lock the Upper
Quick Release
Clamp Lever and
it's ready for use.
GB
