Spectra T50e Menu Map

Spectra T50e Library
General
S, A, O
General Status
Drives Status > Drives screen
Inventory Status > Inventory screen
Import/Export Status >
Import/Export screen
S, A, O
Inventory
Inventory for
(select partition)
Source list (for a move)
Process Queued Ejects
Destination
Destination list (for a move)
Move Queue
Move queue list
Start Moves
S, A, O
Metrics
Power Consumption
Storage Density
S, A, O
Import/Export
Open Door
Bulk Load
Bulk Unload
Recycle
(Encrypted Media)
S, A, O
MLM
(Media Lifecycle Management)
MLM Reports
Partitions (select partition or total
library)
Reports
Media Health
Remaining Capacity
Load Count
Write Errors
Cleans Remaining
Born On Date
Exported Media
Last Write Time
Last Read Time
MLM Details
Save MLM Report
Report All Media Lifecycle Data
Report Selected Data
S, A, O
Robot Usage
Robot Utilization
This map is current for the BlueScale12.6.44 release. The BlueScale user interface changes as features are added or modified. Check
support.spectralogic.com/documentation/user-guides/,
Technical Support Portal to see if you have the latest version of this document.
© 2009–2015 Spectra Logic Corporation. BlueScale, CC, Spectra, SpectraGuard, Spectra Logic, TeraPack, and TranScale are registered trademarks of Spectra Logic Corporation. ArchiveGrade,
BlackPearl, IntraCloud, nTier Verde, and Verde are trademarks of Spectra Logic Corporation. All rights reserved worldwide. All other trademarks and registered trademarks are the property of
their respective owners.
BlueScale Menu Map
MENU
Configuration
S or A
Partitions
(Cleaning or Storage)
C & S: Name & Media Type
S: Exporter
Exporter
Emulation
S: Spare Drives
(assign to partition)
C & S: Chambers and Drives
C & S: Storage (number of slots)
S: Entry/Exit Port Mode
S: Drives
S: Clean Partition (only if one exists)
S: MLM Media Verification
Enable PreScan
FullScan
QuickScan
QuickScan using Global Spare
S: Encryption (if logged in)
BlueScale
Spectra TKLM
S: Partition Users
S: Drive IDs
C & S: Save Library Configuration
S or A
DLM
(Drive Lifecycle Management)
Details
Drive Details
Drive Traces
Remove
Replace
Clean
Test
Reset
S or A
Settings
Library Name
Refresh Rate
Web Server Port
Enable SSL
Online Access to Spectra Logic
Email Auto-Configuration Save
S or A
Option Keys
New (add an option key)
Hardware ID
S or A
Mail Users
New (To, From, SMTP IP Address,
Message Types)
Edit
(To, From, SMTP IP Address,
Message Types)
Delete
S or A
MLM
Enable MLM
Enable Alerts (Non-Certified Media)
Enable Alerts
(Load Count Discrepancies)
Minimum Cleaning Passes
Maximum Tape Loads
Enable Media AutoDiscovery
Minimum Idle Minutes
PostScan Blackout Periods
S or A
Network
*
Setting (DHCP or Static)
(Static IP) Address, Subnet, Gateway
S or A
Date & Time
Date
Time
or the Spectra T50e Library Release Notes and Documentation Updates on the
Maintenance
S or A
AutoSupport
Send Log Set
Manage Profiles
Configure Alarms
Log Forwarding
S or A
Utilities
Basic Utilities
Calibrate Touch Screen
Display Controller Environment
Display EC Information
Display Firmware Versions
Force Log Flush
Save Library Configuration
Advanced Utilities
Restore Library Configuration
S or A
Traces
LCM Traces
Can Log
Error Log
Action Log
Connection Log
GPIO Log
Event Log
Lock Log
Web Server Log
Message Log
Inventory Log
Kernel Log
AutoSupport Log
Encryption Log
HHM Log
MLM Log
Component Traces
Logical Library Trace
Motion Trace
Motion Geometry
Motion Pools
Motion Inventory
Motion Options
S or A
MLM
Discover Media
Stop Discovery (only visible when
Discover Media is running)
Pause PostScan (only visible
when PostScan is running)
Manual PostScan
Delete Records
Download MLM Database
(remote access only)
Download DLM Database
(remote access only)
S or A
Package Update
Begin Library Update
Begin Drive Update
Manage Packages
Manage Package Servers
Security
S, A, O
Switch Users
Login
Logout
S
Edit Users
New (Add a New User)
Edit (Existing User)
Delete (Existing User)
S
Encryption
Encryption User Login
Encryption Configuration
Spectra TKLM
Configure
– Single User Mode
– Multi-User Mode
Check Key Files
Import Key
Add Key
– Moniker
Export Key
Delete Key
Notes:
1)
Available at the library's front panel touch
screen only.
2)
Do not use the Advanced Utilities unless
®
instructed to by SpectraGuard Support.
3) ®
Requires a current BlueScale Software
Support Key.
4)
Available with BlueScale Encryption
Professional edition only.
5)
Requires LTO-4 or later generation Fibre
Channel drives.
6)
Requires LTO-5 or later generation Fibre
Channel drives.
*
= The factory default setting.
Feature Availability:
This feature is
available to this user type:
S) Superuser
– Controls all aspects of library
use, configuration, and security, including
all encryption activities.
A) Administrator
–
Performs same actions as
Superuser except for creating or editing
library users and accessing encryption.
O) Operator
– Moves, imports, and exports
cartridges.
