- Page 1 Spectra T50e Power Supply Installation or Replacement Instructions PN 90970022 Revision A...
- Page 2 LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, BOTH OF WHICH ARE EXPRESSLY DISCLAIMED. In no event shall Spectra Logic be liable for any loss of profits, loss of business, loss of use or data, interruption of business, or for indirect, special, incidental or consequential damages of any kind, even if Spectra Logic has been advised of the possibility of such damages arising from any defect or error.
- Page 3 Installing or Replacing a Power Supply These instructions describe how to install a power supply in a T50e library. Ensure that the work area is free from conditions that could cause electrostatic discharge (ESD). Discharge static electricity from your body by touching a known grounded surface, such as a computer’s metal chassis.
- Page 4 Installing or Replacing a Power Supply 1. Prepare the library—Access the back of the library. Screws Cover plate Figure 1 Power supply cover plate. a. Remove the screws securing the cover plate using a #2 Phillips screwdriver. b. Set the plate and screws aside. 2.
- Page 5 Finger screws Slide the power supply straight out of the library. Figure 4 Remove the power supply. Note: After removing the new power supply from its packaging, keep the packaging to return the old power supply to Spectra Logic.
- Page 6 Wait while the library completes its power-on sequence, which takes from six to nine minutes depending on your library configuration. 4. Package the power supply module and ship it to Spectra Logic as described in Returning Components below.
- Page 7 Returning Components 2. Fold the bag snugly around the component and tape it closed (see Figure 5). Figure 5 Wrap the component in an anti-static bag (generic component shown). 3. Place the bottom air cushion, plastic side up, in the shipping box. 4.
- Page 8 1. Before you ship a component back to Spectra Logic, obtain a Return Materials Authorization (RMA) number from a SpectraGuard Technical Support representative. Spectra Logic needs this number to identify the part on its arrival.
