Summary of Contents for Stirling SICT60
- Page 1 60cm Induction Cooktop Model Number SICT60 INSTRUCTION MANUAL IM Version No.: V1.5 Issue Date: 04/2018 MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018...
-
Page 2: Welcome
Welcome Congratulations on choosing to buy a STIRLING® product. All products brought to you by STIRLING® are manufactured to the highest standards of performance and safety and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 3 Year In Home Warranty. We hope you will enjoy using your purchase for many years to come. -
Page 3: Table Of Contents
13 Operation of Cooktop 18 Cooking Guidelines 19 Heat Settings 20 Care and Cleaning 21 Hints and Tips 22 Troubleshooting 24 Technical Specification 26 Repair and Refurbished Goods or Parts Notice 27 Warranty Returns MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018... -
Page 4: Warranty
You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018... -
Page 5: General Safety Instructions
• Do not let your body, clothing or any item other than suitable cookware contact the Induction glass until the surface is cool. • Metallic objects such as knives, forks, spoons and lids should not be placed on the cooktop surface since they can get hot • Keep children away. MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018... - Page 6 CAUTION • A steam cleaner is not to be used. RISK OF FIRE • The appliance is not intended to be operated by means of an external timer or separate remote-control system. MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018...
-
Page 7: Product Overview
2. Max. 2000 W zone 1 × Quick Start Guide 3. Max. 1500 W zone 1 × Warranty Card 4. Max. 2000 W zone 5. Glass plate 6. Control panel 7. ON/OFF control MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018... - Page 8 In the event that the carton is to be disposed of, please recycle all packaging where possible. Plastic wrapping can be a suffocation hazard for babies and young children; please ensure all packaging materials are out of their reach and disposed of safely. MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018...
-
Page 9: Getting Started
Note: Under all circumstances, make sure the induction cooktop is well ventilated and the air inlet and outlet are not blocked. Note: The safety distance between the cooktop and a cupboard above should be at least 760mm. MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018... - Page 10 • The isolating switch will be easily accessible to the customer with the cooktop installed. • You consult local building authorities and by-laws if in doubt regarding installation. • You use heat-resistant and easy-to-clean finishes (such as ceramic tiles) for the wall surfaces surrounding the cooktop. MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018...
- Page 11 • The power supply cable must not touch any hot parts and must be positioned so that its temperature will not exceed 75˚ C at any point. MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018...
- Page 12 • The cable must not be bent or compressed. • The cable must be checked regularly and replaced by authorised technicians only. • The bottom surface and the power cord of the cooktop are not accessible after installation. MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018...
-
Page 13: Operation Of Cooktop
Use pans with a diameter as large as the graphic of the zone selected. Using a pot a slightly wider or smaller reduces the efficiency. Pots less than 140 mm could be undetected by the cooktop. Always centre your pan on the cooking zone. (Fig. 8) Fig. 8 MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018... - Page 14 • The pan you’re using is not suitable for induction cooking; or, • The pan is too small or not properly centered on the cooking zone. Note: No heating takes place unless there is a suitable pan on the cooking zone. MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018...
- Page 15 ON/OFF control ( ) in an emergency. Please note that when you next use the cooktop, you will have to unlock the controls prior to the next operation. MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018...
- Page 16 The display will show the remaining time and the timer indicator will flash for 5 seconds. Buzzer will beep for 30 seconds and the timer indicator shows “- -” when the setting time finished. MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018...
- Page 17 When a pot is removed, the induction cooktop will stop heating immediately and the cooktop will automatically switch off after 2 minutes. People with a heart pace maker should consult with their doctor before using this unit. MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018...
-
Page 18: Cooking Guidelines
When an unsuitable size or non-magnetic pan (e.g. aluminium), or some other small item (e.g. knife, fork, key) has been left on the cooktop, the cooktop automatically go on to standby in 1 minute. The fan will keep cooling down the induction cooktop for a further 1 minute. MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018... -
Page 19: Heat Settings
• Rapid simmering • Cooking rice 5 - 6 • Pancakes 7 - 8 • Sautéing • Cooking pasta • Stir-frying • Searing • Bringing soup to the boil • Boiling water MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018... -
Page 20: Care And Cleaning
4. Wipe the area completely dry back on. with a paper towel. 5. Switch the power to the cooktop back on. MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018... -
Page 21: Hints And Tips
1300 11 4357 two digits are displayed, alternating, in the cooking timer display. MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018... -
Page 22: Troubleshooting
(F5 for Zone #1, F8 for Zone #2) Temperature sensor of the IGBT failure. F9/FA (short circuit/open circuit for Zone #1) Replace the power board. Temperature sensor of the IGBT failure. FC /FD (short circuit/open circuit for Zone #2) MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018... - Page 23 The display board of Replace the display communicate part is board. damaged. The Main board is Replace the power damaged. board. Fan motor sounds The fan motor is Replace the fan. abnormal. damaged. MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018...
-
Page 24: Technical Specification
Observe any local regulations regarding the disposal of electrical consumer goods and dispose of it appropriately for recycling. Contact your local authorities for advice on recycling facilities in your area. MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018... - Page 25 This page is intentionally left blank MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018...
-
Page 26: Repair And Refurbished Goods Or Parts Notice
1/32 Wangaratta St 118 Campbell Street Richmond VIC 3121 Collingwood VIC 3066 Australia Australia Email: support@residentiagroup.com.au Email: support@residentiagroup.com.au Helpline hours of operation: Mon–Fri 9:00 AM - 5:00 PM MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018 0000 000 000 www.xxxxxxx.com... - Page 27 MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018...
- Page 28 This page is intentionally left blank MODEL: SICT60 | PRODUCT CODE: 60148 | 04/2018...
