60cm Gas Cooktop
Model Number SGC62
INSTRUCTION MANUAL
IM Version No.: V1.3
Issue Date: 06/2016
MODEL: SGC62 | PRODUCT CODE: 53593 | 06/2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SGC62 and is the answer not in the manual?

Questions and answers

Summary of Contents for Stirling SGC62

  • Page 1 60cm Gas Cooktop Model Number SGC62 INSTRUCTION MANUAL IM Version No.: V1.3 Issue Date: 06/2016 MODEL: SGC62 | PRODUCT CODE: 53593 | 06/2016...
  • Page 2: Welcome

    Welcome Congratulations on choosing to buy a STIRLING® product. All products brought to you by STIRLING® are manufactured to the highest standards of performance and safety and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 3 Year In Home Warranty. We hope you will enjoy using your purchase for many years to come.
  • Page 3: Table Of Contents

    04 Warranty 05 General Safety Instructions 07 Product Overview 09 Installation 16 Instructions 19 FAQ’s and Trouble Shooting 20 Other Useful Information 22 Repair and Refurbished Goods or Parts Notice 23 Warranty Returns MODEL: SGC62 | PRODUCT CODE: 53593 | 06/2016...
  • Page 4 You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. MODEL: SGC62 | PRODUCT CODE: 53593 | 06/2016...
  • Page 5: Warranty

    No space heating: Do not use this cooktop for space heating purposes. Ventilation: Heat, steam and moisture will be created when the cooktop is in use. Take care to avoid injury and ensure the kitchen is adequately ventilated. MODEL: SGC62 | PRODUCT CODE: 53593 | 06/2016...
  • Page 6 Contact our after sales support line for advice. Liability: We assume no liability for any eventual damages to property or injury to persons caused by misuse of the product or noncompliance with these instructions. MODEL: SGC62 | PRODUCT CODE: 53593 | 06/2016...
  • Page 7: Product Overview

    6 Trivet 1 × Auxiliary Burner 3.6Mj, (1000W) 2 × Semi Rapid Burner 6.3Mj, (1750W) 1 × Rapid Burner 10.8Mj, (3000W) 2 × Trivets Enamel 4 × Burner Control Knobs Stainless Look MODEL: SGC62 | PRODUCT CODE: 53593 | 06/2016...
  • Page 8 10 Cooktop Surface 11 Pan Support Trivet Note Installation Hardware Installation Hardware is not shown. 4 × Fixing Brackets 4 × Zinc Tapping Screws Sealing Tape — Instruction manual Quick start guide Warranty Card MODEL: SGC62 | PRODUCT CODE: 53593 | 06/2016...
  • Page 9: Installation

    150mm above the cooktop surface across the entire length (depth, width), indicated in Fig. 1. The 150mm protected surface may be ceramic tiles or another approved non-combustible material. MODEL: SGC62 | PRODUCT CODE: 53593 | 06/2016...
  • Page 10 60mm from edge of hob from a side or rear wall. To install the cooktop in your bench Fig. 3 make an opening as per Fig. 3. MODEL: SGC62 | PRODUCT CODE: 53593 | 06/2016...
  • Page 11 15mm below the underside of the cooktop. This panel must have adequate ventilation (V) equal or greater than ≥ 30mm to the rear (Fig. 5). Fig. 5 The panel below the hob must be easily removable to enable servicing if and when required. MODEL: SGC62 | PRODUCT CODE: 53593 | 06/2016...
  • Page 12 (Fig. 7, B) to the cooktop and tighten the screws (Fig. 7, C) securely shown in Fig. 7. This is very important. The other side of the clamp must be located on the underside of the bench top, as seen in Fig. 7. Fig. 7 MODEL: SGC62 | PRODUCT CODE: 53593 | 06/2016...
  • Page 13 LPG. Gas conversions can be carried out by an authorised and licenced gasfi tter/plumber. WARNING: Always isolate the cooktop from the electricity supply before changing the injectors and/or adjusting the minimum fl ow of the burners. MODEL: SGC62 | PRODUCT CODE: 53593 | 06/2016...
  • Page 14 Follow gas connection instructions but do not install the NG regulator (Fig. 9 on page 13) but install the brass test point fi tting (Fig. 10 on page 13). MODEL: SGC62 | PRODUCT CODE: 53593 | 06/2016...
  • Page 15 • When lit, each burner produces a well defined blue flame without any yellow tipping. • Each burner flame remains lit when the respective control knob is rotated quickly from the Maximum to the Minimum aperture position. MODEL: SGC62 | PRODUCT CODE: 53593 | 06/2016...
  • Page 16: Instructions

    • After use, always turn the control knob to the Closed position Note: It is possible to light the burners using matches or another fl ame device MODEL: SGC62 | PRODUCT CODE: 53593 | 06/2016...
  • Page 17 Cooking with your Gas Cooktop Use appropriately sized pans for each burner, see Table 1. PAN TABLE Burners Pan Diameter (Table 1) R Rapid 20-22cm SR Semi Rapid 16-18cm A Auxiliary 10-14cm Fig. 14 MODEL: SGC62 | PRODUCT CODE: 53593 | 06/2016...
  • Page 18 Gas saved. possible handle damage. Choice of cooking pots/pans For a small burner, use For a large burner, use a small pot or pan. a large pot or pan. Fig. 16 MODEL: SGC62 | PRODUCT CODE: 53593 | 06/2016...
  • Page 19: Faq's And Trouble Shooting

    If your gas cooktop is still not working then call our aftersales support team or your local licenced gasfitter or plumber to arrange a service call. MODEL: SGC62 | PRODUCT CODE: 53593 | 06/2016...
  • Page 20: Other Useful Information

    (Fig. 19). If it does not fi t, you are trying to fi t the burner body onto the wrong burner. • To check that all parts are reassembled correctly, light the burners and allow them to dry out. Fig. 18 Fig. 19 MODEL: SGC62 | PRODUCT CODE: 53593 | 06/2016...
  • Page 21 Observe any local regulations regarding the disposal of electrical consumer goods and dispose of it appropriately for recycling. Contact your local authorities for advice on recycling facilities in your area. MODEL: SGC62 | PRODUCT CODE: 53593 | 06/2016...
  • Page 22: Repair And Refurbished Goods Or Parts Notice

    Please telephone us on 1300 11 43 57 or write to us at: Residentia Group 1/32 Wangaratta St Richmond VIC 3121 Australia Email: support@residentiagroup.com.au Helpline hours of operation: Mon–Fri 9:00 AM - 5:00 PM 0000 000 000 www.xxxxxxx.com MODEL: SGC62 | PRODUCT CODE: 53593 | 06/2016...
