Page 1: Ceramic Cooktop
Ceramic Cooktop Model Number STR-SGC INSTRUCTION MANUAL AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017 N13275... -
Page 2: Welcome
Welcome Congratulations on choosing to buy a STIRLING product. ® ® All products brought to you by STIRLING are manufactured to the highest standards of performance and safety and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 3 Year in Home Warranty. -
Page 3: Table Of Contents
08 Product Overview 10 Installation 19 Getting Started 21 Instructions 29 FAQs & Troubleshooting Guide 30 Other Useful Information 35 Repair and Refurbished Goods or Parts Notice AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017... -
Page 4: Warranty Details
You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017... -
Page 5: General Safety Instructions
If it is necessary for younger family members to be in the kitchen, ensure that they are kept under close supervision at all times. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017... - Page 6 Pot and pan handles may become hot during use; position handles away from the edge of the cooktop and out of children’s reach. Never cook directly on the glass surface without a pot or pan. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017...
- Page 7 • Avoid burns: While in operation, direct contact with the cooktop surface may cause burns! Take utmost care when the equipment is in use. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017...
-
Page 8: Product Overview
Product Overview Ceramic Cooktop Layout Control Panel Layout NOTE: See opposite for part descriptions. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017... - Page 9 • The illustrations of parts shown here are not to scale; they are for reference purposes only. • This cooktop must be installed by a qualified professional. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017...
-
Page 10: Installation
Alterations to the domestic wiring system must only be made by a qualified electrician. Failure to follow this advice may result in electric shock or death. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017... - Page 11 If the appliance is going to be used for prolonged periods of time, additional ventilation may be required. If in doubt about your ventilation requirements, consult your qualified installer. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017...
- Page 12 • Electrical impedance: This appliance must only be connected to an electricity supply with system impedance of no more than 0.427 ohm. If necessary, please consult your electricity provider for system impedance information. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017...
- Page 13 There are ventilation holes around the outside of the cooktop. When you put the cooktop into position, you must ensure that these holes are not blocked by the benchtop. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017...
- Page 14 • The minimum distance between the cooktop and the cupboard above the hotplate must be at least 650mm. Fig. 2 (mm) (mm) (mm) 50 min. 30 min. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017...
- Page 15 Screw Bracket Screw hole Base • Adjust the bracket position to suit your benchtop thickness (Fig. 5). Cooktop Benchtop Cooktop Benchtop Bracket Bracket Fig. 5 Screw Screw AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017...
-
Page 16: Electrical Connection
3mm between the contacts. • IMPORTANT: The appliance must NOT be connected to the mains supply by means of a 10A cord and plug. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017... - Page 17 For a single-phase installation using a 3-core cable (not supplied), the bridges (supplied) can be used to join the two live contacts and the two neutral contacts inside the terminal block. Fig. 6 AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017...
- Page 18 Installation (Cont.) Wiring and Connection Diagram AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017...
-
Page 19: Getting Started
(e.g. a utensil or a cloth) covering them. Even a thin film of water may make the controls difficult to operate. • Each touch control has a corresponding visual display (indicator light). Fig. 7 AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017... -
Page 20: Choosing The Right Cookware
Always lift pans off the ceramic hob – do not slide, or they may scratch the glass (Fig. 10). Fig. 10 IMPORTANT: Always use appropriate cookware. Never cook directly on the glass surface without a pot or pan. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017... -
Page 21: Instructions
• You can modify the heat setting at any time during cooking. • By holding down either of the [ – ] or [ + ] control, the value will adjust up or down. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017... - Page 22 The residual heat indicator can also be used as an energy saving function, for keeping food warm on a cooking zone that is still hot. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017...
-
Page 23: Safety Features
For example, if a cooking zone is left unattended while set to heat at power level 4, it will switch off automatically after four hours. Table 1 Power Level Time Limit (hrs:min) 1–3 8:00 4–6 4:00 7–9 2:00 AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017... -
Page 24: Using The Timer
[ -- ] (Fig. 23). Fig. 23 IMPORTANT: The cooktop will continue to cook, this timer function is a minute minder only, it does not turn the cooktop ON or OFF. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017... - Page 25 [ – ] (Fig. 31). NOTE: To change the time after the timer is set, start from step 1. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017...
-
Page 26: Cooking Guidelines
– the firmer it feels the more ‘well done’ it will be. 5. Leave the steak to rest on a warm plate for a few minutes to allow it to relax and become tender before serving. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017... - Page 27 Do not use the cooktop if the surface is broken or cracked. Switch off the appliance immediately to avoid the possibility of electric shock and contact our after sales support centre for advice. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017...
-
Page 28: Heat Settings
• Rapid simmering • Cooking rice 5–6 • Cooking pancakes • Sautéing 7–8 • Cooking pasta • Stir-frying • Searing • Bringing soup to the boil • Boiling water AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017... -
Page 29: Faqs & Troubleshooting Guide
This is normal for cookware clicking noises. your cookware (layers and does not indicate a fault. of different metals vibrating differently). AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017... -
Page 30: Other Useful Information
Take care and check suitability of your cleaning agents. • Never leave cleaning residue on the cooktop; the glass may become stained. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017... - Page 31 • The cooktop may beep and turn itself off, and the touch controls may not function while there is liquid on them. • Make sure you wipe the touch control area dry before turning the cooktop back on. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017...
- Page 32 Do not attempt to repair the appliance yourself! Our after sales support centre stocks the following spare parts for the STR-SGC STIRLING Ceramic Cooktop. To purchase a part, call the centre on 1300 886 649 or email us at info@tempo.org •...
-
Page 33: Technical Specifications
NOTE: Due to continued product improvement, images and illustrations in this manual may vary slightly from the product purchased. All images in this manual are for reference only. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017... - Page 34 This page has been left blank intentionally. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017...
-
Page 35: Repair And Refurbished Goods Or Parts Notice
Tempo (Aust) Pty Ltd ABN 70 106 100 252 PO BOX 6056 Frenchs Forest, Sydney, Australia NSW 2086 Tempo Help Desk: 1300 886 649 (Aust) (Operating Hours: Mon-Fri 08:30am to 06:00pm EST) Email: info@tempo.org AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017... -
Page 36: The Product
Instruction Manual Revision Index Version No Issue Date Description V1.0 19 October 2016 Original release V1.1 11 November 2016 Minor updates on pages 15, 18, 24, 25 AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-SGC PRODUCT CODE: 56487 06/2017...
