4. Bill of Materials

Part Reference
C1, C3, C5, C7, C12, CAP, 10 μF, 50 V, ±20%, X7R, 1210
C14, C18
C2 CAP, 100 pF, 50 V, ±20%, C0G, 0603
C3 CAP, 390 pF, 100 V, ±20%, X7R, 0805
C4, C6, C8, C9, C13, CAP, 0.1 μF, 50 V, ±10%, X7R, 0805
C15
C10 CAP, 1.5 nF, 250 V, ±10%, X7R, 0805
C16 CAP, 390 pF, 50 V, ±10%, C0G, 0603
D1, D2 DIO, SCHOTTKY, 60 V, 1 A, SMB
D4, D5, D11 LED, RED, 631 nM, 20 mA, 2 V, 54mcd, 0603
D10 DIO, FAST, 300 V, 1.0 A, SMA
J1, J2 CONN, TERM BLOCK 2POS, 2.54 MM, RT PCB
J3 CONN, TERM BLOCK 3POS, 2.54 MM, RT PCB
J6, J7, J8, J9, J10 Header, Single Pin, Tin Plated
J11, TP7, TP11 SOLDER TURRET, 0.064 inD, 0.105 inL
JP1, JP2 Header, 2x1, 0.1 in pitch, Tin Plated
JS1 JS2 Shunt, 1x2, 0.1 in pitch, Tin plating
R1 RES, 182 K, 1/10 W, ±1%, ThickFilm, 0603
R2 RES, 7.87 K, 1/16 W, ±1%, ThickFilm, 0603
R3 RES, 200 K, 1/10 W, ±1%, ThickFilm, 0603
R4 RES, 100 Ω, 1/16 W, ±1%, ThickFilm, 0603
R5 RES, 100 Ω, 1/10 W, ±1%, ThickFilm, 0603
R6, R7, R8, R9, R28, RES, 10 K, 1/16 W, ±1%, ThickFilm, 0603
R29
R10 RES, 25 Ω, 1/4 W, ±5%, ThickFilm, 1206
R11 RES, 10 Ω, 1/4 W, ±1%, ThickFilm, 1206
R12 RES, 1.0 Ω, 1/4 W, ±5%, ThickFilm, 1206
R13, R14 RES, 0 Ω, 2 A, ThickFilm, 0805
S1 SWITCH, PB, NO, MOMENTARY, TACTILE, LIGHT
TOUCH 130GF, 6MM, PTH
SF1, SF2, SF3, SF4 HDW, BUMPON CYLINDRICAL, 0.312 x 0.215, BLK
T1 TRANSFORMER, POWER, FLYBACK, 5kV ISOLATED,
2.5uH, 100nH LEAKAGE, 7:1, 5:1, SMT
TP1, TP2, TP3, TP4, TESTPOINT, BLACK, PTH
TP5, TP6, TP14
silabs.com | Smart. Connected. Energy-friendly.
Table 4.1. Si8281-EVB Bill of Materials
Description
UG167: Si8281-EVB User's Guide
Manufacturer Manufacturer Part
Venkel C1210X7R500-106M
Venkel C0603C0G500-101M
Venkel C0805X7R101-391M
Venkel C0805X7R500-104K
Venkel C0805X7R251-152K
Venkel C0603C0G500-391K
Diodes Inc.
Lite-On Tech. LTST-C190KRKT
Fairchild
PHOENIX CONTACT
PHOENIX CONTACT
Samtec TSW-101-07-T-S
Mill-Max 2551-2-00-44-00-00-0
Samtec TSW-102-07-T-S
Samtec SNT-100-BK-T
Venkel CR0603-10W-1823F
Venkel CR0603-16W-7871F
Venkel CR0603-10W-2003F
Venkel CR0603-16W-1000F
Venkel CR0603-10W-1000F
Venkel CR0603-16W-1002F
Venkel CR1206-4W-250J
Venkel CR1206-4W-10R0F
Venkel CR1206-4W-1R0J
Venkel CR0805-10W-000
Panasonic EVQ-PAD04M
3M
UMEC
Kobiconn
Bill of Materials
