RF wireless wall mounted 240V RGB/W controller
Parameter
Remote
Operation Voltage
Part No.
ML-2820
100-240VAC
Receiver(purchased separately)
Iuput Voltage
Part No.
ML-1009FAWi
12-36VDC
Product Size
75.0
ML-2820
Feature
1 zone
Save 3 Scenes
Sensitive Glass Touch Panel
RF Signal
White&black
North American Size
5
Operation
DIMENSIONS
Frequency
ø/h (mm)
Touch Sensor
434MHz
120x75x29.1
Current
Output
4x5A
4x(60-180)W
Constant voltage
Installation
Button introduction
Color Wheel:
Touch to choose color
Warm white & Cold White &
Natural White, mixed by RGB
Brightness
Remarks
Save Color:
Long Touch S1/S2/S3 to save your
favorite colors
Remarks
Wiring diagram
1)Sender
Connection
L
110V-230VAC
N
Diagram
ML-2820
L
L
NC
N
N
Short touch to choose the color R.G.B.W
Long touch to dim brightness of R.G.B.W
Switch: Short
touch
to switch on/off
Color Running Button:
Short touch to start or Pause color
running mode;
Long touch to adjust speed (10 built-in
color running mode)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Melec ML-2820
Summary of Contents for Melec ML-2820
- Page 1 RF wireless wall mounted 240V RGB/W controller Installation ML-2820 Feature 1 zone Save 3 Scenes Sensitive Glass Touch Panel RF Signal Button introduction White&black North American Size Color Wheel: Touch to choose color Short touch to choose the color R.G.B.W Long touch to dim brightness of R.G.B.W...
