5.1 RAV-363AH8-PE
No. PARTS NAME
1 Compressor
2 Outdoor unit fan motor
Running capacitor for outdoor fan motor
3
4 Magnetic contactor
5 High pressure switch
6
Solenoid coil
Crankcase heater
7
Outdoor unit sensor for heat-exchanger
8
temperature
9 Transformer for outdoor unit
10 Fuse
Sensor for cooling operation in low ambient
1 1
temperature
12 Reverse Phase Protector
Sensor for delivery pipe temperature
13

5. SPECIFICATIONS OF ELECTRICAL PARTS

TYPE
ZR49K3-TFD
SMF-230-63N-2
SMF-230-39N-2
EEP2G405HQA114
FMca-1S
ACB-2TBO4W
CHV-AC240V
FT-67
STR-4AB
SPECIFICATIONS
Output (Rated) 3.0kW, 2 pole, 3 phase, 380/415V, 50Hz
Winding resistance 3.73ý at 20°C
Output (Rated) 63W, 6 pole, 1 phase, 230V, 50Hz
Output (Rated) 39W, 6 pole, 1 phase, 230V, 50Hz
AC 400V, 4 µF
AC 230V, 50Hz
2
Tripping pressure 30kg/cm G
Resetting pressure 23kg/cm 2 G
AC 220~240V
AC 240V, 28W
Maximum input
15.5mA
AC 187~264V
5A
Maximum input
15.5mA
- 9 -
°C -12 10
ký 67.5 21.3
°C -12 10
ký 67.5 21.3
°C 23 100
ký 57.0 3.4
