Panel Explanation; Vigor 2762N - Draytek Vigor2762 Quick Start Manual

3 . P a n e l E
3 . P a n e l E
3 . 1 V i g o r 2 7 6
3 . 1 V i g o r 2 7 6
LED
(Activity)
(Wireless LAN
On/Off/WPS)
(USB)
(DSL)
~
(LAN1/2/3/4)
x p l a n a t i o n
x p l a n a t i o n
2 n
2 n
Status
Blinking
Off
On
Blinking
Blinking in
unison with
(Activity)
Off
On
Blinking
On
Blinking
(Slowly)
Blinking
(Quickly)
On
Blinking
Off
Explanation
The router is ready and operating normally
The router is powered off
2.4GHz Access Point is active
Data is being transmitted on the router's 2.4
GHz wireless interface
WPS pairing mode is active for two minutes
2.4GHz Access Point is turned off
USB device is connected and ready for use
Data is being transmitted over USB
DSL connection synchronised
DSL connection not currently synchronising or
not detected
DSL connection is synchronising
Ethernet LAN (RJ45) is connected
Data is transmitting (sending/receiving)
Ethernet LAN is disconnected
3
