No.
LED
ACT
WAN2/ WAN1
LTE
(1)
DMZ
USB
QoS
VPN
WCF
(2)
WAN1, WAN2 / P6
Lef t LED
Right LED
All manuals and user guides at all-guides.com
p
l
a
n
a
t
i
o
n
p
l
a
n
a
t
i
o
n
7
L
7
L
St at us
Explanat ion
Of f
The rout er is powered of f .
Blinking
The rout er is powered on and running
normally.
On
Int ernet connect ion is ready.
Of f
Int ernet connect ion is not ready.
Blinking
The dat a is t ransmit t ing.
On
LTE device is connect ed and ready f or use.
Of f
LTE device is not det ect ed, or has serious
problem (e. g. , no SIM card, SIM pin error, SIM
deact ivat ed, and et c. ).
Blinking
Slowly: LTE device is in dialing up.
Quickly: The dat a is t ransmit t ing.
On
The DMZ f unct ion is enabled.
Of f
The DMZ f unct ion is disabled.
Blinking
The dat a is t ransmit t ing.
On
USB device is connect ed and ready f or use.
Of f
No USB device is connect ed.
Blinking
The dat a is t ransmit t ing.
On
The QoS f unct ion is act ive.
Of f
The QoS f unct ion is inact ive.
On
The VPN t unnel is act ive.
Of f
VPN services are disabled
Traf f ic is passing t hrough VPN t unnel.
Blinking
On
The Web Cont ent Filt er is act ive. (It is
enabled f rom Firewall >> General Setup ).
Of f
WCF is disabled.
On
The port is connect ed.
Of f
The port is disconnect ed.
Blinking
The dat a is t ransmit t ing.
On
The port is connect ed wit h 1000Mbps.
Of f
The port is connect ed wit h 10/ 100Mbps.
