Draytek Vigor2762 Quick Start Manual page 9

Interface
Wireless LAN
ON/OFF/WPS
Factory Reset
USB1~USB2
GigaLAN1~LAN4 RJ-45 Gigabit Ethernet connectors for local network devices.
DSL
I / O
PWR
Description
WLAN On - Press the button and release it within 2 seconds.
When the wireless function is enabled, the green LED will be
on
WLAN Off - Press the button and release it within 2 seconds to
turn off the WLAN function. When the wireless function is not
enabled, the LED will be off
When WPS is enabled in the router's web interface, press this
button for more than 2 seconds to enable WPS pairing mode
Restore the default settings.
Usage: Turn on the router (ACT LED is blinking). Press gently
and hold for more than 5 seconds. When the ACT LED blinks
rapidly, release the button and the router will restart with its
factory default configuration.
Connector for a USB 3G/4G modem, storage, printer or USB
Thermometer.
GigaLAN4 can be configured as the Ethernet WAN port, see
Section 5.3 for details
RJ-11 connector for ADSL or VDSL line
Power Switch. Turns the unit on (I) or off (O)
Connector for the power adapter
4
