2
.
P
a
n
e
l
E
2
.
P
a
n
e
l
E
2
.
1
L
E
D
2
.
1
L
E
D
LED
PWR
ACT
USB
SFP+
Left
P3 ~
P12
Right
x
p
l
a
n
a
t
i
o
n
x
p
l
a
n
a
t
i
o
n
Status
Explanation
On
The router is powered on.
Off
The router is powered off.
Blinking
The system is active.
Off
The system is hanged.
On
The USB device is installed and ready.
Off
No USB device is installed.
On
The fiber connection is established.
Off
No fiber connection is established or the system is
hanged.
On
The Ethernet link is established on corresponding port.
Off
No Ethernet link is established.
Blinking
The data is transmitting.
On
The Ethernet link is established on corresponding port
with 1G Mbps or above.
Off
The Ethernet link is established on corresponding port
with less than 1G Mbps.
2
