Harmonic MediaCenter 2200B Quick Reference Manual

MediaCenter™ 2200B Quick Reference Guide
Front panel components
1
MediaCenter
Drive numbering and file system configurations
3 2
2 1
0
1
Rear panel components
1. Boot drive
2. Power button/LED
3. LTC In connector
4. 1 Gb Eth ports (1, 2 from left to right.
For system management)
* Use these ports to connect to Spectrum I/O (for example, MediaPorts) only; DO NOT use these ports for any other purpose.
Harmonic Technical Support: +888 673 4896 (Americas), +65 6542 0050 (Asia Pacific), + 44 1252 555 450 (EMEA),
+7 495 926 4608 (Russia, CIS), +81 3 5565 6737 (Japan), +86 10 8391 3313 (China, mainland)
4
6
6 9 8
5 8
4 3 7
4
1 2 3
6
5. MediaPort Ethernet array*
6. Redundant, hot-swappable
power supplies (0, 1 from left to right)
7. 10 Gb Ethernet ports (for file transfers)
8. VGA port (for Service only)
2
1. Air vents 3. Status LEDs
2. Power indicator 4. Power button
5
# Drives RAID set
12 11
2 x (4+2)
12 SAS
11 10
2 x (4+2)
12 SAS
10 9
5
7 8 9 10
3
5. Reset button
Capacity per drive Storage capacity
4 TB 32 TB
2 TB 16 TB
11
9. RS-232 serial (for Service only)
10. USB ports (for Service only)
11. BMC (for Service only)
006-0187-001 Rev. A
