Harmonic MediaGrid ContentServer 4000
Front Panel Components
1 Disk drives
Numbered 0-23, starting at top left
Rear Panel Components
1
1 Power supply units
2 Serial port
3 VGA port
Harmonic Technical Support: +888 673 4896 (Americas), +65 6542 0050 (Asia Pacific), + 44 1252 555 450 (EMEA),
+7 495 926 4608 (Russia, CIS), +81 3 5565 6737 (Japan), +86 10 6569 5580 (China, mainland)
Quick Reference Guide
1
2 Bezel LED control connector
Controller A
Controller B
5
2
3
4
4
BMC port
5
USB ports
6
SAS ports
3 Power button
4 Control panel
PCIe slots 6 - 1 (left to right)
Unused
6
7
8
7
10 GbE NIC ports
8
Onboard SAS ports
2
3
A
4
B
006-0217-001 Rev. B
