MediaDirector™ 2202 Quick Reference Guide
Rear Panel Components
3
2
1
eth 5 eth 4 eth 3 eth 2
1 Gb Quad Port Ethernet Expansion Card
1. Power Button
2. Alt/Boot Button
3. Reset Button
4. LTC IN Connector
* Use these ports to connect to MediaPorts only; DO NOT use these ports for any other purpose, including plugging directly into a network.
MediaPort Ethernet Array
Link
Link
Amber = 100 Mbps
Green = 1 Gbps
Off = Inactive or 10 Mbps
Ethernet Port Status LEDs
Link
Link
Amber = 1 Gbps
Green = 100 Mbps
Off = Inactive or 10 Mbps
Harmonic Technical Support: +888 673 4896 (Americas), +65 6542 0050 (Asia Pacific), + 44 1252 555 450 (EMEA),
+7 495 926 4608 (Russia, CIS), +81 3 5565 6737 (Japan), +86 10 8391 3313 (China, mainland)
4
0 2
1 3
LTC IN
11
ixeth 1
OR
10 Gb Dual Port Optical Fibre Expansion Card
5. MediaPort Ethernet Array*
6. Fibre Channel Loop Status LEDs
7. Fibre Channel Loop 0-7
8. Optional Expansion Card Slot
Activity
Activity
Green (blink) = Normal
Activity
Activity
Yellow (blink) = Normal
5
4 6 8 10 12 14
5 7 9 11 13 15
ETH 0 ETH 1
10
9
ixeth 0
OR
1 Gb Quad Port Ethernet Card Status LEDs
Link
Link
Amber = 1 Gbps
Green = 100 Mbps
10 Gb Dual Port Ethernet Status LEDs
Off = Inactive
Green, solid = On
Green, blinking = Activity on port
(Look slightly upwards to view the LED)
7
6
0 1 2 3
0 1 2 3
4 5 6 7
4 5 6 7
8
ixeth 1 ixeth 0
10 Gb Dual Port Ethernet Expansion Card
9. Ethernet Ports
10. For service use only
11. Redundant Power Supplies
Activity
Activity
Green (blink) = Normal
10 Gb Dual Port
(Optical)
10 Gb Dual Port
28-0295 Rev. G
