C H A P T E R 8 : S H O R T C U T F U N C T I O N R E F E R E N C E
600 CALL TELEPHONE NUMBER
700 OUTPUT CONTROL
701-704 PGM#1 output control [701]...
800 PLAY/REC ALARM VOICE MESSAGES
801-806 Play/rec msg for input #1[801] ...
820 PLAY/REC COMMON MESSAGES
820 Play/rec common message[820]
900 PROGRAM TELEPHONE NUMBERS
901-909 Telephone number #1 [901], Telephone number #2 [902] ...
930 MESSAGE TYPE
931-939 Message type for tel#1 [931], Message type for tel#2 [932], ...
960 CALL ACKNOWLEDGE CODE
961-969 Call ack. code for tel: 1 [961], Call ack. code for tel#2 [962] ...
980 COPY ACKNOWLEDGEMENT CODE 1 TO ALL
984 ENABLE REMOTE LISTEN-IN
985 VIEW EVENT LOG
986 CHANGE USER CODE
999 QUIT/EXIT PROGRAMMING
C H A P T E R 9 : I N P U T S / O U T P U T S A P P E N D I X
This section should be filled in by the engineer who installed the system.
9 . 1 I N P U T S

Inputs

Description
1 (onboard)
2 (onboard)
3 (onboard)
9 . 2 O U T P U T S

Outputs

Description
1 (onboard)
2 (onboard)
Pyronix Ltd
- 4 on board outputs
-6 onboard inputs
Inputs Description
4 (onboard)
5 (onboard)
6 (onboard)
Outputs Description
3 (onboard)
4 (onboard)
