Thermo Scientific Smart-Vue 2.0 Getting Started Manual

Smart-Vue
Getting started with your USB receiver
Follow these instructions to get your system up and running with a USB receiver and Smart-Vue
Before you begin
1. These instructions provide a brief
introduction to the
monitoring system. Please read the
Smart-Vue User Guide to benefit from
the full potential of your installation.
Access the manual from the software
(Help User Manual) or on your
è
CD-ROM).
2. Do not plug in your USB receiver until
instructed by the installer software.
3. Software installation on the server
computer must be performed by a
system administrator.
4. We recommend connecting
server to a uninterruptable power
supply for maximum reliability.
Set up sensor reading and data transfer
1. Press F11.
2. Drag with your mouse to move the sensor
from the default "SDP" group (if that's where
it is) into a group of your own. You may
create new groups here as well (click on a
receiver first).
3. Modules read their sensors and transfer the
data periodically. Click on Unlock sensor
settings tabs at the bottom of the screen to
use the dials to set Use the dials to set the
Measurement and Transfer intervals.
Set up operating limits and alarms
1. Go to the Alarm settings tab and click on
the On/Off buttons to enable alarms.
2. Set Low and High alarms as desired.
3. The Delay value determines how long the
system will wait, after detecting an out-
of-bounds condition on a sensor, before
triggering an alert to warn a person.
4. Click on Close when done and follow the
instructions on the screen.
5. See the user manual for more information
on this process in case you encounter any
problems.
Thermo Scientific
™
Install software & receiver
1. Insert the Smart-Vue CD into the
Smart-Vue drive on your computer.
2. Select Full installation and follow
the instructions on your screen.
3. Select
installation wizard.
4. When prompted, plug in your USB
receiver and continue.
5. Click on Detect to add the receiver to
your system.
6. Click on Next to create a user name
and password. The default super
administrator is "thermo", with the
the password "thermo".
7. Finish the wizard.
8. Launch Smart-Vue Client and login.
2.0 Monitoring System
USB receiver in the
Move the
sensor into
your group
F11 è Sensor settings tab for measurement and transfer intervals
F11 è Alarm settings tab to assign operating range limits and alarms
wireless module.
™
Add a sensor
1. With Smart-Vue Client
press the large button on the front
of the module you are installing, and
hold it 3 seconds or until Searching
is displayed on the module screen.
2. If the receiver is within wireless
range, the module establishes the
wireless connection automatically
and is displayed in Smart-Vue Client.
If the module does not detect the
receiver automatically,
repeat these steps or install it
manually (F11 > F11, as described in
the user manual).
Unlock settings
and set read and
transfer intervals
Set alarm
limits
running,
you may
