  • Page 1 FMT100 User Manual V0.04...

  • Page 2: Table Of Contents

    ..............10 ECHNICAL NFORMATION ABOUT INTERNAL BATTERY ....................11 LECTRICAL CHARACTERISTICS ....................11 BSOLUTE AXIMUM ATINGS CONNECTION, PINOUT, ACCESSORIES .................. 12 FMT100 : ............12 OW TO INSERT MICRO CARD INTO DEVICE FMT100 ....................13 NSTALLING DRIVERS ..........................14 INOUT LED ........................
  • Page 3 EOFENCE SETTINGS 5.12 ....................38 DOMETER SETTINGS 5.13 ......................40 LUETOOTH SETTINGS 5.13.1 How to connect Bluetooth Hands Free adapter to FMT100 device ......41 5.13.2 Device’s log using your mobile phone..............43 5.14 ...................... 44 LUETOOTH SETTINGS 5.15 I/O &...
  • Page 4 6.3.1.8 Backup Server Mode (ID=2010) ..................55 6.3.1.9 Backup Server Domain (ID=2008) ..................56 6.3.1.10 Backup Server Port (ID=2008) ................... 56 6.3.1.11 Protocol (ID=2009) ......................56 6.3.1.12 Open Link Timeout (ID=1000) ................... 56 6.3.1.13 Response Timeout (ID=1001).................... 56 6.3.1.14 Sort By (ID=1002) ......................57 6.3.1.15 FOTA WEB Settings: Status (ID=13003) ................
  • Page 5 6.7.1.5 Source (ID=11007) ......................66 6.7.1.6 Green Driving Duration (ID=11008) ..................66 6.7.1.7 SMS Text (ID=8034) ......................66 6.7.2 Over Speeding parameters ..................67 6.7.2.1 Scenario (ID=11100) ......................67 6.7.2.2 Max Speed (ID=11104) ....................... 67 6.7.2.3 SMS Text (ID=8032) ......................67 ......................
  • Page 6 6.11.1.6 SMS Text (ID=8031) ......................74 6.11.1.7 Eco Score Allowed Events (ID=11804) ................75 6.11.1.8 Calculation Source (ID=11806)..................75 6.11.1.9 Odometer value (km) (ID=11807) ..................75 6.12 ......................75 LUETOOTH SETTINGS 6.12.1.1 BT Radio (ID=800) ......................75 6.12.1.2 Local Name (ID 801) ......................75 6.12.1.3 Local PIN (ID=802)......................

  • Page 7: Introduction

    The device uses a 10 V... 30 V DC power supply. The nominal voltage is 12 V DC. The allowed range of voltage is 10 V... 30 V DC. To avoid mechanical damage, it is advised to transport the FMT100 device in an impact- proof package.

  • Page 8: Legal Notice

    GSM network to server. This device is perfectly suitable for applications, which need location acquirement of remote objects. It is important to mention that FMT100 has two pin interface. FMT100 also has a USB port for device status log output and device configuration.
  • Page 9  GPRS class 12;  SMS (text, data);  Integrated GNSS receiver;  Up to -161 dBm GNSS receiver sensitivity. Hardware features:  Built-in movement sensor;  Built-in Bluetooth 4.0;  Internal High Gain GNSS antenna;  Internal High Gain GSM antenna; ...

  • Page 10: Technical Features

    Internal fuse: 3A, 125V Weight: 63 g. Figure 1 FMT100 view & dimensions (tolerance ±2mm) Technical Information about internal battery Li-ion rechargeable battery, 3.7 V, 170 mAh. Energy consumption has been tested at 12 V voltage with no battery charging.

  • Page 11: Electrical Characteristics

    ≥170 0.64 - 0.66 0 – 45 battery FMT100 internal battery is used for detecting external voltage disconnection. CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS. Electrical characteristics VALUE Min.

  • Page 12: Connection, Pinout, Accessories

    3 CONNECTION, PINOUT, ACCESSORIES How to insert micro SIM card into FMT100 device:   Unscrew the screws. Remove the cover.   Insert micro SIM card as shown Insert SD card as shown (top (bottom slot). slot).  Attach the cover and put the screws back in.

  • Page 13: Installing Fmt100 Drivers

    Please download MediaTek inbox COM Port drivers from Teltonika website: http://avl1.teltonika.lt/downloads/FMT1000/MS_USB_ComPort_Driver_exe_v1.1032.3.zip Installing drivers: Extract and run FP_INBOX_InstallDriver_v1.1032.3.exe. This driver is used to detect FMT100 device connected to the computer. Click 'Next' in driver installation window (figures below): Figure 2 Driver installation window This will launch device driver installation wizard.

  • Page 14: Pinout

    Setup will continue installing drivers and will display a window about successful process at the end. Click 'Finish' to complete setup: Figure 4 Driver installation window You have now installed drivers for FMT100 device successfully. Pinout Color Pin Name Description...

  • Page 15: Operational Basics

    While in sleep mode, FMT100 turns GPS module off and it is still making new periodic records. As a result power usage decreases, in turn saving vehicle battery.

  • Page 16: Online Deep Sleep Mode

    It keeps adding these intervals until it is time to make a record, then FMT100 records its location and adds odometer value, which is equal to the sum of all distances, measured every second.

  • Page 17: Features

    Harsh cornering is monitored only when following conditions are fulfilled:  Ignition is ON;  Vehicle speed is equal or higher than 30 km/h. Some new parameters and IO elements are introduced with FMT100. Table 3 Green Driving new parameters Parameter ID...

  • Page 18: Over Speeding

    Accelerometer scenarios 4.5.1 Towing Detection Helps to inform driver about car moving with ignition off. FMT100 generates event when car is being towed or raised, for example in case of vehicle evacuation. FMT100 activates towing function when these conditions are met: •...

  • Page 19: Crash Detection

    8 extended enabled crash event records are sent without any IO elements, only GNSS and accelerometer data if it is in configured range. 4.5.3.1 Crash Trace operation If Crash Trace is enabled FMT100 will collect acceleration data every 40 milliseconds. Bluetooth Bluetooth can work in two modes - slave or master.

  • Page 20: Configuration

    (e. g. GPRS connection is not available) FMT100 will start storing records to flash memory. It will send data later when GPRS is available again. Note that FMT100 can have memory full of records. In such case it will start deleting the oldest records in order to save new ones. Please be aware that sending all data records to server may take some time.
  • Page 21 ‘Create new configuration’ – opens offline configurator. ‘Connect to device’ (on the right, with connected device info) – connects to the device. Figure 7 Configurator control bar Control bar buttons description: ‘Load from device’ – loads the configuration from device. ‘Save to device’...

  • Page 22: Status Window

    Status window Figure 8 Status window Status window shows main information about the connected device. It can be divided into five main parts: 1. Device Info – shows general information about connected device e. g. Device Name, Device IMEI, etc. 2.

  • Page 23: System Settings

    2. Ignition source, where user can choose between power voltage, digital input 1 and accelerometer ignition sources 3. Object Motion Detection Settings, where user can configure 3 ways how FMT100 will detect stopped movement, and change its working mode; 4. Static navigation settings, where user can turn static navigation on or off;...
  • Page 24 Table 7 Configuration parameters Movement Source Vehicle on Stop mode Vehicle Moving mode Ignition If ignition (DIN1) is logic low If ignition (DIN1) is logic high (recommended) Movement Internal movement sensor does Internal movement sensor detects (movement sensor) not detect movement movement GPS fix is available and vehicle GPS fix is available and vehicle...

  • Page 25: Gprs Settings

    Open Link Timeout is used to set timeout of link between FMT100 and AVL application termination. If FMT100 has already sent all records it waits for new records before closing link. If new records are generated in the period of this timeout, and minimum count to send is reached, they are sent to AVL application.

  • Page 26: Data Acquisition Settings

    This functionality allows having different AVL records acquire and send parameters values when object is moving or stands still. Vehicle moving or stop state is defined by Stop Detection Source parameter. There are 3 ways for FMT100 to switch between Vehicle on Stop and Vehicle Moving modes see section 5.7.
  • Page 27 ‘Min Saved Records’ defines minimum number of coordinates and I/O data that should be transferred with one connection to server. If FMT100 does not have enough coordinates to send to server, it will check again after time interval defined in “Sending Period”.
  • Page 28 FMT100 is able to collect records using four methods at the same time: time, distance, angle and speed based data acquisition: Min. time period Distance based data acquiring (Min. distance) – records are being acquired when the distance between previous coordinate and current position is greater than defined parameter value.

  • Page 29: Sms \ Call Settings

    Essential fields in ‘SMS’ part are ‘Login’ and ‘Password’. The login and password are used with every SMS sent to FMT100. If login and password are not set, in every SMS sent to FMT100 device two spaces before command have to be used (<space><space><command>).
  • Page 30 Incoming Call setting defines what device does, when it receives a call. It can hang-up or report its position. FMT100 works with synchronized GPS time which is UTC+0, with SMS Event Time Zone option customer can configure his time zone and get SMS with correct time.

  • Page 31: Gsm Operators List

    Figure 16 Operator list configuration If operator list is left empty, it will allow using GPRS to any GSM operator as Home operator. Please note that FMT100 will work in Unknown mode only unless data sending is allowed – GPRS context is enabled.

  • Page 32: Green Driving

    If any of three cases are satisfied event is generated. Record is saved and sent to server (FMT100 must be configured properly). Event value is multiplied by 10 before sending/saving record to get more precision when displaying data*.

  • Page 33: Over Speeding

    2. When speed is higher than highway speed, FMT100 adds highway fuel consumption x % of highway fuel consumption every y km/h, by default FMT100 adds 20% every 50 km/h. It means that fuel consumption is (1.2 * Highway Fuel Consumption) on 140 km/h speed, (1.4 * Highway Fuel Consumption) on 190 km/h speed.

  • Page 34: Accelerometer Features Settings

    Duration (in ms), check Ignition state. If Ignition is still OFF during configured "Ignition check after Event Timeout" time, then event is generated. If configured - sends SMS event message or makes a call. Function will be reactivated after FMT100 again detects change of Ignition state from ON to OFF.

  • Page 35: Crash Detection

    During set time period, then device will generate an event. Threshold and duration values are set depending of accident power which you want to detect. FMT100 can detect a slight tapping on the device (Threshold = 100 mg, Duration = 1 ms) or can detect severe accident...

  • Page 36: Unplug Detection

    2 Bytes Length Bytes New IO element is introduced with FMT100 – crash accelerometer data. New IO element ID is 0x101. It stores data from x, y and z axes. Crash accelerometer data structure is shown below. Data being sent is integer 16 type and values are in mG.

  • Page 37: Auto Geofence Settings

    Figure 22 Unplug Detection parameters 5.10 Auto Geofence settings Auto Geofence – the last known position after movement = off. If your car’s being taken away – you can be notified. The shape and size of the geofence zones are parameters. It is possibility to state whether entering in or out of the geofence triggers an asynchronous message.

  • Page 38: Manual Geofence Settings

    Figure 23 Auto Geofence configuration window 5.11 Manual Geofence settings Manual Geofence enables the user to configure certain actions when the vehicle enters/leaves any specific point. It is configurable by coordinates or user can select Geozones on a map. Figure 24 Manual Geofence configuration window 5.12 Trip \ Odometer settings Trip scenario offers user to configure Trip feature.
  • Page 39 value is reset to zero. When the next trip starts counting continuously starts from the beginning again. Figure 25 Trip \ Odometer settings If I/O Odometer is enabled and Continuous Distance Counting variable (Mode) is set “Between Records”, then the distance is going to be counted only between every record made. This value is written to I/O Odometer value field and reset to zero every new record until Trip stops.

  • Page 40: Bluetooth Settings

    Local name can be set according to your needs. If this field is empty, name will be automatically generated: FMT100xx_<imei last chars> Local PIN - PIN code which will be used when external device will try to pair with FMT100. NOTE: FMT100 supports ONE connection at a time. Security mode possible options:...

  • Page 41: How To Connect Bluetooth Hands Free Adapter To Fmt100 Device

    PIN+MAC list – PIN is used, also external device’s MAC address needs to be in Authorized MAC list c) MAC list only – connection to FMT100 is possible only if external device MAC is in Authorized MAC list. d) None – no security enabled.
  • Page 42 Figure 31 Bluetooth settings 1. When device configuration is loaded press „Bluetooth“ settings. 2. Turn on BT Radio by pressing „Enable (visible)“. You could leave “Local name” box empty (then device name will automatically be “FMT100xx_[last 7 IMEI digits]”) or type your own desirable name.

  • Page 43: Device's Log Using Your Mobile Phone

    Figure 33 Incoming Call Action settings 7. After all these steps press „Save to device“ to save configuration. 8. Now you can disconnect FMT100 device from a PC or stay connected if you want to make further changes to configuration.

  • Page 44: Bluetooth 4.0 Settings

    I/O element. Enabled or disabled field – allows enabling I/O element so it is added to the data packet and is sent to the server. By default all I/O element are disabled and FMT100 records only GNSS coordinates.
  • Page 45 condition to get value 0, then antenna is damaged and short circuit. GNSS PDOP Probability * 10; 0-500 GNSS HDOP Probability * 10; 0-500 External Voltage Voltage: mV, 0 – 30 V Speed Value in km/h, 0 – xxx km/h GSM Cell ID GSM base station ID Location Area code (LAC), it depends on GSM...

  • Page 46: Obd Functionality Description

    Commanded EGR Commanded Exhaust gas recirculation data EGR error Exhaust gas recirculation error data Fuel level Fuel Tank Level Input Distance travelled since codes Distance travelled since error codes clear clear Barometric pressure Absolute Barometric Pressure Control module voltage Control module voltage Absolute load value Absolute load value data Ambient air temperature...

  • Page 47: Data

    I/O property elements. 6 SMS COMMAND LIST Basic commands Commands are case sensitive. While FMT100 operates in Sleep mode and user tries to send SMS message it will arrive to FMT100 device, because GSM module is enabled. Table 12 SMS commands list...

  • Page 48: Getinfo

    “setparam” and “setdigout” SMS is used to configure device. Parameter ID consists of 3 or 5 digits. Detailed list of parameters and IDs can be found in chapter number 5.2 “System parameters” Example: “username password setparam 102:0” will disable sleep mode. Multiple value setting in one sms: Example: “username password setparam...

  • Page 49: Getgps

    6.1.1.4 getgps Response details Description Indicates valid (1) or invalid (0) Gps data Count of currently available satellites Latitude (Last good Latitude) Long Longitude (Last good Longitude) Altitude Speed Ground speed, km/h Ground direction, degrees Date Current date Time Current GMT time Example: GPS:1 Sat:0 Lat:54.666042 Long:25.225031 Alt:0 Speed:0 Dir:0 Date: 17/1/9 Time: 12:52:30 6.1.1.5 ggps...

  • Page 50: Setdigout

    2. # - APN 3. # - GPRS LOGIN 4. # - GPRS PASSWORD 5. # - IP 6. # - PORT 7. # - MODE (0-TCP/1-UDP) Parameters are separated by comma (no spaces needed). In case you don’t need to enter parameter (Login/Pass) –...

  • Page 51: Obdinfo

    6.1.1.13 obdinfo Response details Description LIST of OBD info Protocol, VIN, Adaptive Timing value, requested PID counter, OBD application state, available vehicle PIDs, mil status, number of DTCs Example: Protocol:5,VIN:N/A,TM:5,CNT:5,ST:OBDDATA REQUESTING,P1:0x0,P2:0x0,P3:0x0,P4:0x0,MIL:0,DTC:0,ID0 6.1.1.14 btgetlist btgetlist command needs argument what list should be printed! btgetlist 0;...

  • Page 52: Battery Charge Mode (Id=110)

    GPS module to sleep, in deep sleep mode (value 2) module turns GPS module to sleep and device is deregistered from network (note, that FMT100 do not receive SMS while in deep sleep). In online sleep (value 3), device behavior is the same as in deep sleep, but GSM module stays on.

  • Page 53: Sleep Timeout (Id=103)

    6.2.2 Sleep Timeout (ID=103) Sleep timeout is time after which FMT100 goes to GPS Sleep, Deep Sleep or Online Deep Sleep modes if other requirements are met. It is measured in minutes. Minimum Maximum Recommended Goes with (depends on) Value...

  • Page 54: Time Synchronization (Id=900)

    Sets the IP of the first NTP server. Minimum Maximum Recommended Goes with (depends on) Value value value value parameters type avl1.teltonika.lt 6.2.2.9 NTP Server 2 (ID=903) Sets the IP of the second NTP server. Minimum Maximum Recommended Goes with (depends on) Value value value value...

  • Page 55: Apn Username (Id=2002)

    APN Password (ID=2003) 6.3.1.3 APN Username (ID=2002) Parameter defines APN username. In case operator does not use username for login, value should be empty. Minimum Maximum Recommended Goes with (depends on) Value value value value parameters type GPRS Context (ID=2000) 30 char APN (ID=2001) Empty...

  • Page 56: Backup Server Domain (Id=2008)

    Minimum Maximum Recommended Goes with (depends on) Value value value value parameters type Backup Server Domain (ID=2007) Backup Server Port (ID=2008) S8[30] Backup Server Protocolo (ID=2009) 6.3.1.9 Backup Server Domain (ID=2008) Parameter defines backup server IP address. Example: 212.47.99.62 Minimum Maximum Recommended Goes with (depends on)

  • Page 57: Sort By (Id=1002)

    6.3.1.14 Sort By (ID=1002) Record sorting parameter is responsible for record sorting order. Value of 0 arranging data starting from newest, while value of 1 arranging data starting from oldest. Minimum Maximum Recommended Goes with (depends on) Value value value value parameters type...

  • Page 58: Fota Web Settings: Status (Id=13003)

    ATTENTION! Some GSM operators may disconnect the device from an active data link if the device doesn’t send any data for a very long time, even if active data link timeout is set to maximum value. The amount of time that an operator keeps the link open depends solely on the operator.

  • Page 59: Data Acquisition Settings

    Data Acquisition settings 6.4.1 Home Network GSM operator code “On stop” parameters 6.4.1.1 Min Period (ID=10000) This parameter indicates time interval in seconds in order to acquire new record. If value is 0 it means no records by min period will be saved. Minimum Maximum Recommended...

  • Page 60: Min Angle (Id=10052)

    6.4.2.3 Min Angle (ID=10052) This parameter indicates angle in degrees in order to acquire new record. If angle difference between last recorded coordinate and current position is greater than defined value, new record is stored. This parameter is operational, when speed is higher than 10 km/h. If value is 0 it means no records by min angle will be saved.

  • Page 61: Min Saved Records (Id=10104)

    6.4.3.2 Min Saved Records (ID=10104) This parameter defines minimum number of records in one data packet that can be sent to server. It has higher priority than Data Send Period (ID=10105). Minimum Maximum Recommended Goes with (depends on) Value value value value parameters...

  • Page 62: Min Speed (Id=10153)

    6.4.4.4 Min Speed (ID=10153) This parameter indicates speed difference in order to acquire new record. If speed difference between last recorded coordinate and current position is greater than defined value, new record is stored. If value is 0 it means no records by min distance will be saved. Minimum Maximum Recommended...

  • Page 63: Unknown Network Gsm Operator Code "Moving" Parameters

    6.4.6 Unknown Network GSM operator code “Moving” parameters 6.4.6.1 Min Period (ID=10250) This parameter indicates time interval in seconds in order to acquire new record. If value is 0 it means no records by min period will be saved. Minimum Maximum Recommended Goes with (depends on)

  • Page 64: Send Period (Id=10255)

    6.4.6.6 Send Period (ID=10255) This parameter indicates frequency (time interval in seconds) of sending data to server. Minimum Maximum Recommended Goes with (depends on) Value value value value parameters type Min Saved Records 2592000 (ID=10254) SMS \ Call Settings parameters 6.5.1.1 Allow SMS Data Sending (ID=3000) Parameter allows or does not allow sending AVL data using binary SMS.

  • Page 65: Incoming Call Settings (Id=3005)

    6.5.1.6 Incoming Call Settings (ID=3005) Parameter defines action during call: 0 –Do Nothing, 1 – Hang-Up, 2 – Report Position Minimum Maximum Recommended Goes with (depends on) Value value value value parameters type S8[17] 6.5.1.7 Authorized phone numbers (ID=4000-4199) If at least one number is entered then only those number can send messages to device. Number must be entered without “+”...

  • Page 66: Max Acceleration (Id=11004)

    Minimum Maximum Recommended Goes with (depends on) Value value value value parameters type 6.7.1.2 Max Acceleration (ID=11004) It is max allowed acceleration force which can be reached while accelerating without triggering harsh acceleration event. Minimum Maximum Default value Goes with (depends on) Value value value...

  • Page 67: Over Speeding Parameters

    6.7.2 Over Speeding parameters 6.7.2.1 Scenario (ID=11100) Defines priority of overspeeding scenario: 0 – Disabled, 1 – Low Priority, 2 – High Priority, 3 – Panic Priority. Minimum Maximum Recommended Goes with (depends on) Value value value value parameters type 6.7.2.2 Max Speed (ID=11104) It is max allowed speed which can be reached.

  • Page 68: Gnss Fuel Counter Settings

    6.8.2 GNSS Fuel Counter settings 6.8.2.1 City Consumption (L/100km) (ID=11900) Consumption in the city. Minimum Maximum Default value Goes with (depends on) Value value value parameters type Double 6.8.2.2 Highway Consumption (L/100km) (ID=11901) Consumption on highway. Minimum Maximum Default value Goes with (depends on) Value value...

  • Page 69: Fuel Consumption On Idling (L/H) (Id=11907)

    6.8.2.8 Fuel Consumption On Idling (L/h) (ID=11907) Sets fuel consumption while vehicle is idling Minimum Maximum Default value Goes with (depends on) Value value value parameters type Double 6.8.2.9 Higher Speeds Add (%) (ID=11908) Minimum Maximum Default value Goes with (depends on) Value value value...

  • Page 70: Sms Text (Id=8033)

    6.9.1.5 SMS Text (ID=8033) Sets event SMS text. Minimum Maximum Recommended Goes with (depends on) Value value value value parameters type 32 char S8[32] string 6.9.2 Unplug Detection settings Note: „Unplug Detection“ work just in device with battery. 6.9.2.1 Scenario Settings (ID=11500) Sets priority of the scenario: 0 –...

  • Page 71: Towing Detection

    6.9.3 Towing Detection 6.9.3.1 Scenario Settings (ID=11600) Sets priority of the scenario: 0 – Disable, 1 – Low Priority, 2 – High Priority, 3 – Panic Priority. Minimum Maximum Default value Goes with (depends on) Value value value parameters type 6.9.3.2 Eventual Records (ID=11601) Sets priority of the scenario: 0 –...

  • Page 72: Sms Text (Id=8035)

    6.9.3.8 SMS Text (ID=8035) Activation timeout in minutes. Minimum Maximum Default value Goes with (depends on) Value value value parameters type 32 char “Towing” S8[32] string 6.9.4 Crash Detection 6.9.4.1 Scenario Settings (ID=11400) Sets priority of the scenario: 0 – Disable, 1 – Low Priority, 2 – High Priority, 3 – Panic Priority.

  • Page 73: Auto Geofence Settings

    6.10 Auto Geofence settings 6.10.1.1 Scenario Settings (ID=20000) Defines priority of trip scenario: 0 – Disable, 1 – Low Priority, 2 – High Priority, 3 – Panic Priority. Minimum Maximum Recommended Goes with (depends on) Value value value value parameters type 6.10.1.2 Eventual Records (ID=20002) Eventual Records: 0 –...

  • Page 74: Trip \ Odometer

    6.11 Trip \ Odometer 6.11.1.1 Scenario Settings (ID=11800) Defines priority of trip scenario: 0 – Disabled, 1 – Low Priority, 2 – High Priority, 3 – Panic Priority. Minimum Maximum Default value Goes with (depends on) Value value value parameters type 6.11.1.2 Eventual Records (ID=11801) Eventual Records: 0 –...

  • Page 75: Eco Score Allowed Events (Id=11804)

    6.11.1.7 Eco Score Allowed Events (ID=11804) This parameter represents how many eco score events are allowed. Minimum Maximum Recommended Goes with (depends on) Value value value value parameters type 6.11.1.8 Calculation Source (ID=11806) This parameter represents odometer calculation source: 0 – GNSS, 1 – OBD. Minimum Maximum Recommended...

  • Page 76: Security Mode (Id=803)

    Value value value parameters type 0 symbols 8 symbols string 6.12.1.9 Authorized Devices MAC List (ID=830-834) Parameter allows to add an authorized devices MAC for connection to FMT100. Minimum Maximum Default value Goes with (depends on) Value value value parameters...

  • Page 77: I/O#1 Property Parameter Ignition (Id=50000)

    6.13.1.1 I/O#1 property parameter Ignition (ID=50000) Parameter defines I/O property value. Possible values: 0 – Disabled; 1 – Low; 2 – High; 3 – Panic. Minimum Maximum Recommended Goes with (depends on) Value value value value parameters type I/O#1 priority (ID=50000) I/O#1 logic operand (ID=50001) I/O#1 High level (ID=50002) I/O#1 Low level (ID=50003)

  • Page 78: I/O#1 Event Only (Id=50004)

    6.13.1.5 I/O#1 Event only (ID=50004) Parameter defines whether element should be sent only when event is generated. Possible values: 1 – Yes (parameter ID and value is sent when event is generated); 0 – No (parameter ID and value is sent in every record). Minimal Maximum Recommended...
  • Page 79 50015 Uint16 65535 Movement Average 7001 Uint8 Send SMS 8001 String SMS Text 50020 Uint8 Data Mode Priority 50021 Uint8 Data Mode Operand 50022 Uint8 Data Mode Hight level 50023 Uint8 Data Mode Low level 50024 Uint8 Data Mode Event only 7002 Uint8 Send SMS...
  • Page 80 7007 Uint8 Send SMS 8007 String SMS Text External Voltage 50080 Uint8 Priority 50081 Uint8 External Voltage Operand 50082 Uint16 1000 60000 External Voltage Hight level 50083 Uint16 60000 External Voltage Low level 50084 Uint8 External Voltage Event only 50085 Uint16 65535 External Voltage...
  • Page 81 Active GSM Operator 50140 Uint8 Priority Active GSM Operator 50141 Uint8 Operand Active GSM Operator 50142 Uint32 999999 Hight level Active GSM Operator 50143 Uint32 999999 Low level 50144 Uint8 Active GSM Operator Event only 7014 Uint8 Send SMS 8014 String SMS Text 50150...
  • Page 82 50201 Uint8 Fuel Used GPS Operand 50202 Uint32 1000000 Fuel Used GPS Hight level Fuel Used GPS Low 50203 Uint32 1000000 level 50204 Uint8 Fuel Used GPS Event only 50205 Uint16 65535 Fuel Used GPS Average 7020 Uint8 Send SMS 8020 String SMS Text...

  • Page 83: Obd Settings

    6.14 OBD settings OBD settings are confiburable just as I/O Elements parameters. 6.14.1 OBD elements parameters and types Value range Parameter Parameter Default Parameter name Type value Number Of DTC 40100 Uint8 Priority Number Of DTC 40101 Uint8 Operand Number Of DTC 40102 Uint8 High level...
  • Page 84 Intake Map 7043 Uint8 Send SMS Intake Map 8043 String SMS Text Engine RPM 40160 Uint8 Priority Engine RPM 40161 Uint8 Operand Engine RPM 40162 Uint16 16384 Hight level Engine RPM 40163 Uint16 16384 Low level Engine RPM 40164 Uint8 Event only Engine RPM 7044...
  • Page 85 Run time since engine start 40224 Uint8 Event only Run time since engine start 7050 Uint8 Send SMS Run time since engine start 8050 String SMS Text Distance traveled MIL on 40230 Uint8 Priority Distance traveled MIL on 40231 Uint8 Operand Distance traveled MIL on 40232...
  • Page 86 Distance traveled since codes slear 40293 Uint16 65535 Low level Distance traveled since codes slear 40294 Uint8 Event only Distance traveled since codes slear 7057 Uint8 Send SMS Distance traveled since codes slear 8057 String SMS Text Barometric pressure 40300 Uint8 Priority Barometric pressure...
  • Page 87 Absolute fuel rail pressure 40360 Uint8 Priority Absolute fuel rail pressure 40361 Uint8 Operand Absolute fuel rail pressure 40362 Uint16 65535 Hight level Absolute fuel rail pressure 40363 Uint16 65535 Low level Absolute fuel rail pressure 40364 Uint8 Event only Absolute fuel rail pressure 7064 Uint8...

  • Page 88: Ec Declaration Of Conformity

    7 EC Declaration of Conformity...

  • Page 89: Change Log

    CHANGE LOG Date Version Comments 2018-04-19 0.01 Preliminary draft release. Updated Crash Detection, Green Driving functionalities. 2018-05-14 0.02 Added Tracking on Demand functionality. Minor fixes. 2018-05-24 0.03 Changed Figure 20. Minor fixes. 2018-05-29 0.04 Battery information updated Updated information about codec8 and codec8E...
