- Page 1 FM1100 with Light Vehicles Can adapter LV-CAN100 Manual V1.4 Reproduction forbidden without Teltonika, UAB written authorization – All Rights Reserved 1/16...
-
Page 2: Table Of Contents
LV-CAN100 Signaling Led Description ................... 9 Connecting FM1100 with Light Vehicles Can adapter ............... 10 FM11 Configuration ........................11 Parameters ID ..........................14 References ..........................15 Changelog ........................... 16 Reproduction forbidden without Teltonika, UAB written authorization – All Rights Reserved 2/16... -
Page 3: Legal Notice
The device is designed to be mounted in a zone of limited access, which is inaccessible for the operator. All related devices must meet the requirements of standard EN 60950-1. Teltonika is not responsible for vehicle damage caused by installation of adapter. Reproduction forbidden without Teltonika, UAB written authorization – All Rights Reserved... -
Page 4: Purpose Of Light Vehicles Can Adapter Lv-Can100
Purpose of Light Vehicles Can Adapter LV-CAN100 LV-CAN100 is used to listening data from light vehicles. With this adapter FM1100 device is able to collect and send vehicle data. ECU1 CAR CAN L FM1100 CAN100 ECU2 Figure 1 Connection block diagram FM1100 shares the same USB port for connecting adapter and configuring device with PC. - Page 5 3. In next window you must enter path to drivers or browse to the folder which contains drivers and click next. 4. In last window press „Finish“ button. Reproduction forbidden without Teltonika, UAB written authorization – All Rights Reserved 5/16...
- Page 6 Ports (COM & LPT) tab find USB Serial Port line. In this example USB Serial Port is COM3. Please note that “Teltonika LV-CAN100 Bootloader” application supports COM ports numbers not higher than 12. If USB Serial Port is assigned to COM port 13 or higher please follow these steps: 1.
- Page 7 2. Then select “Port Settings” tab and press “Advanced...” button. 3. In opened tab select COM port number not higher than 12 and press OK. Reproduction forbidden without Teltonika, UAB written authorization – All Rights Reserved 7/16...
-
Page 8: Lv-Can100 Configuration
LV-CAN100 configuration Connect bootloader USB adapter to computer and LV-CAN100 device. Figure 2 LV-CANBOOT10 bootloader adapter Start “Teltonika LV-CAN100 Bootloader” application. If you did not receive this application please contact Teltonika sales manager. Figure 3 Teltonika LV-CAN100 Bootloader software 1. In “Teltonika LV-CAN100 Bootloader” application select port that was assigned to USB Serial Port. -
Page 9: Lv-Can100 Signaling Led Description
The LED flashing indicates sending CAN data Behavior: Sending is executed : UART green LED is on, blinks; Sending is not available: UART green LED is off. Figure 4 Adapter signaling led Reproduction forbidden without Teltonika, UAB written authorization – All Rights Reserved 9/16... -
Page 10: Connecting Fm1100 With Light Vehicles Can Adapter
Connect Light Vehicles Can adapter Pin 1 and Pin 2 to cars CAN bus. CAN interface location of the supported light vehicles are described in “Connection of LV-CAN100” manual. Connect car power supply lines to Pin 16 positive, Pin 8 Negative. -
Page 11: Fm11 Configuration
“Save” button. To configure CAN data: 1. In car, connect LV-CAN100 to CAN bus and to the FM1100 device (Figure 6), wait 10 seconds. Note, that car engine must be started. - Page 12 Offline configuration – user can select which CAN data can be read from LV-CAN100 need to be sent to server without connection to adapter. Please note that parameters depend on vehicle manufacturer and vehicle model. Please for further information check “Light Vehicles Can adapter supported cars”...
- Page 13 Figure 8 Configurator example Available CAN Bus IO parameters and configuration can be found in Configurators CAN tab (Figure 8) and in next chapter “Parameters ID”. Reproduction forbidden without Teltonika, UAB written authorization – All Rights Reserved 13/16...
-
Page 14: Parameters Id
Clutch Status 0 – Off 1 – On Parking Headlights 0 – Off 1 – On Low Headlights 0 – Off 1 – On High Headlights 0 – Off Reproduction forbidden without Teltonika, UAB written authorization – All Rights Reserved 14/16... -
Page 15: References
References 1. Light Vehicles Can adapter LV-CAN100 Supported cars 2. Connection of LV-CAN100 3. FM1100 User Manual Reproduction forbidden without Teltonika, UAB written authorization – All Rights Reserved 15/16... -
Page 16: Changelog
Initial release 2012 November 15 Added: SELECTING PROGRAM NUMBER AND FIRMWARE GROUP BY BOOTLOADER 2012 November 20 Minor changes 2012 November 27 Major changes 2013 January 11 Minor changes Reproduction forbidden without Teltonika, UAB written authorization – All Rights Reserved 16/16...
