  • Page 1 IP Mini-Converters JPEG 2000 IP Video/Audio Converters Installation and Operation Guide Version 1.0 Published September 5, 2017...
  • Page 2: Notices

    AJA® and Because it matters.® are registered trademarks of AJA Video Systems, Inc. for use with most AJA products. AJA™ is a trademark of AJA Video Systems, Inc. for use with recorder, router, software and camera products. Because it matters.™ is a trademark of AJA Video Systems, Inc.
  • Page 3: Table Of Contents

    Appendix C – Specifications ......37 IPT-1G-SDI Tech Specs ........37 IPT-1G-HDMI Tech Specs .
  • Page 4 Index........49 IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0 www.aja.com...
  • Page 5: Chapter 1 - Introduction

    IP Mini-Converters ease the cost of extensive monitoring distribution in a facility. The IPT-1G-SDI encodes SDI video and audio as VSF TR-01 compliant JPEG 2000 encapsulated within an MPEG-2 Transport Stream. Similarly, the IPT-1G- HDMI encodes HDMI 1.4 video and audio as VSF TR-01 compliant JPEG 2000 encapsulated within an MPEG-2 Transport Stream.
  • Page 6: Features

    • Rugged, fanless, portable design • Full 10-bit pixel processing pipeline • Network (LAN) control and status • Quick network setup with AJA eMini-Setup software IPT-1G-HDMI HDMI to JPEG 2000 IP Video and Audio Converter • Full size HDMI 1.4 video input •...
  • Page 7: System Requirements

    NOTE: Safari is the preferred web browser for control on the Mac, and additionally Chrome and Firefox on Windows. Other web browsers may work, but AJA cannot guarantee consistent operation for all web browsers or web browser versions.
  • Page 8: I/O Connections

    I/O Connections Figure 2. IPT-1G-SDI Connections 2 Channel Control Unbalanced Analog Audio Output (RCA Jacks) Ready LED Input SDI Connector Loop Through Media SDI Connector Port Lock LED +5-20 VDC Power Input Figure 3. IPT-1G-HDMI Connections 2 Channel Control Unbalanced...
  • Page 9: Ready, Lock, And Lan Led Behavior

    The Ready LED illuminates green when the unit has finished powering up and is ready to use. The Lock LED behavior is as follows: • Off (indicating not locked) when no Program Clock Reference (PCR) has been received. IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0 www.aja.com...
  • Page 10: Installation Overview

    Therefore, when installing the units, mount in a location where they have access to air for proper cooling. Do not stack the IP Mini-Converters with other mini converters. IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0 www.aja.com...
  • Page 11: Initial Installation For Ip Mini-Converters

    Play) services enabled, so they are discoverable through Windows Explorer (for networked Windows PCs). The eMini-Setup application, available as a free download from the AJA website, is used to identity the IP Mini-Converters' current IP addresses, if configured, or to manually set the initial network configuration to work in your environment.
  • Page 12: Chapter 2 - Emini-Setup

    Subsequently, that device can then be reconfigured over that network, using its IP address and built-in web server. NOTE: The eMini-Setup application is only used to setup selected Ethernet capable AJA devices, and cannot be used to connect to or setup other AJA Mini-Converters.
  • Page 13: Installing Emini-Setup

    When finished, an AJA eMini-Setup shortcut will be installed on the desktop, and you will be able to locate the eMini-Setup application in the AJA folder in the Programs listing. NOTE: If the eMini-Setup application already exists on the PC, a different Setup Wizard appears.
  • Page 14: Mac Installation

    PC Startup To run eMini-Setup on a PC, double-click on the AJA eMini-Setup icon on your desktop, or open the AJA folder in the program list and click on the AJA eMini- Setup application located inside the eMini-Setup folder. IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0...
  • Page 15: Mac Startup

    Sn - This is the factory set unique serial number of your AJA device. If you ever call AJA Support for service, you may be asked for this number. A status field at the bottom of the screen shows if the eMini-Setup application is connected and communicating with an AJA device.
  • Page 16: Control Network Tab Screen

    Control Network Tab Screen Use this Control Network tab to change the network setup on the connected AJA device. You must click the Apply button to initiate any network configuration changes. IP Address Type - Choose from DHCP or Static IP Address.
  • Page 17: Media Network Tab Screen

    Media Network Tab Screen Use this Media Network tab to change the media network setup on the connected AJA device. You must click the Apply button to initiate any network configuration changes. IP Address Type - Choose from DHCP or Static IP Address.
  • Page 18: Update Tab Screen

    4. Click the Update tab. Click the Browse button. Navigate to the firmware (.ajas extension), open it, and confirm the update. Progress will be shown via the “Progress” bar. 5. After the update, the AJA device must be rebooted by clicking on the Reboot button in the prompt window. See also: "Firmware Screen"...
  • Page 19: Info Tab Screen

    AJA Support for service or technical support. System Name - This field allows you to give your AJA device a unique name. This can be useful if you have several attached to a Mac/PC via USB so you can distinguish between them easily.
  • Page 20: Chapter 3 - Ip Mini-Converter Web Interface

    (cross-over) cables without any configuration or strapping required. NOTE: Safari is the preferred web browser for control on the Mac, and additionally Chrome and Firefox on Windows. Other web browsers may work, but AJA cannot guarantee consistent operation for all web browsers or web browser versions.
  • Page 21: Web Browser Via Ethernet

    Ethernet LEDs of that device at a 1 second rate. Parameters and Information The rest of the screen displays all the parameter selections and information available for the selected IP Mini-Converter screen. IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0 www.aja.com...
  • Page 22: Ipt-1G-Hdmi Status Screen

    • For values with sliders, fine control is achieved using the arrow keys on the keyboard to move the slider the minimum amount. The numeric value can also be clicked on to enter a specific value. IPT-1G-HDMI Status Screen IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0 www.aja.com...
  • Page 23: Ipr-1G-Hdmi Status Screen

    IPR-1G-HDMI Status Screen The Status screen reports the current status and settings for: • Input Status • Network Status • Firmware Status Each group of parameters can be opened or closed. IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0 www.aja.com...
  • Page 24: Config Screen For Ipt-1G Models

    Config Screen for IPT-1G Models Figure 10. IPT-1G-SDI Config Screen 1 of 2 The IPT-1G Config Screen, shown in two parts, has the parameters required for the general operation of the IPT-1G Mini-Converters. System Name - Defines a name for the system and gives it a unique identifier.
  • Page 25 Figure 11. IPT-1G-SDI Config Screen 2 of 2 Video Stream Mode - Select ELSM or Non-ELSM. Select ELSM to add an elementary stream header to the video stream including image data metadata parameters associated with decoding and displaying the image data.
  • Page 26: Config Screen For Ipr-1G Models

    (Optional) The UDP destination port of the stream. • Value Range: 0 - 65535 • Default Value: 0 • A value of zero implies the destination port number of packets is to be ignored. IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0 www.aja.com...
  • Page 27 When Program Selection is set to “Auto - First Program in PAT” or “Auto - Lowest Program Num,” Active Program Num displays the auto-selected Program Number and cannot be edited. Program PID - Reports the PID of the selected program. IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0 www.aja.com...
  • Page 28: Presets Screen

    Presets Screen Controls Factory Reset - Factory Reset recalls all editable parameters to their factory default settings. Individual presets and Network settings, such as the IP Addresses, are not affected. IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0 www.aja.com...
  • Page 29: Network Screen

    20 current presets. Network Screen Use the Network Screen: Control tab to configure or modify settings for the Control LAN Ethernet port. IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0 www.aja.com...
  • Page 30 Consult your network administrator about how to set this value. • If IP Address Type is set to DHCP, the IP address is set automatically by the network DHCP server and cannot be entered here. IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0 www.aja.com...
  • Page 31: Firmware Screen

    The Update Firmware screen allows you to download and install a firmware update from AJA. To Download and Install Updated Firmware 1. Visit the AJA website (aja.com) to locate and download the updated software. The following page provides support information and will include links to locations where you can download updates: IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0...
  • Page 32: Booting The Ip Mini-Converters From The Safeboot Firmware

    2. After downloading the software update to your local drive, use the Browse or Choose File button to locate the local software copy. 3. Follow the prompts to load the new firmware into your unit. 4. After the firmware has finished installing, reboot the unit by disconnecting power for a few seconds, then reconnecting power.
  • Page 33 Installing Updated Firmware" on page 31. Following a successful firmware update and reboot, the message "None" displays under the Alarms heading. Figure 16. The alarm message after a successful firmware update IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0 www.aja.com...
  • Page 34: Appendix A - Frequently Asked Questions (Faq)

    Appendix A – Frequently Asked Questions (FAQ) Question How many channels of analog audio can be input to the IPT-1G-SDI and IPT-1G- HDMI for encoding? Answer Question How many channels of analog audio can be output or monitored by the IPR-1G-...
  • Page 35 Answer Yes. Question Do I have to use a network switch when working with combinations of IPT-1G-SDI, IPT-1G-HDMI, IPR-1G-SDI and / or IPR-1G-HDMI? Answer You do not have to use a switch, as IPT to IPR connections can be point-to-point.
  • Page 36: Appendix B - Example Configurations

    Destination IP Address 239.0.1.20 239.0.1.20 Control Network Control Network 192.168.1.10 192.168.1.20 Web User Interface Web User Interface Media Network Media Network DHCP DHCP (identity on the network) (identity on the network) IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0 www.aja.com...
  • Page 37: Appendix C - Specifications

    • 5.53” x 4.48” x 0.954” (140.462mm x 113.792mm x 24.232mm) Weight • 0.6 lb (0.3 kg) Power • Uses AJA power supply model DWP-U-R1, included with purchase • 100-240V, 50/60 Hz Universal input • +5 to 20V DC regulated, 12 watts max Environment •...
  • Page 38: Ipt-1G-Hdmi Tech Specs

    NOTE: IPT-1G-SDI uses approximately 12 watts of power and convection cooling. It will be very warm to the touch, which is normal. When installing the unit, mount in a location where it has access to air for proper cooling. Do not stack the IPT-1G-SDI with other Mini-Converters.
  • Page 39: Ipr-1G-Sdi Tech Specs

    • 5.53” x 4.48” x 0.954” (140.462mm x 113.792mm x 24.232mm) Weight • 0.6 lb (0.3 kg) Power • Uses AJA power supply model DWP-U-R1, included with purchase • 100-240V, 50/60 Hz Universal input • +5 to 20V DC regulated, 12 watts max Environment •...
  • Page 40 • 5.53 x 4.48 x 0.954 (140.462mm x 113.792mm x 24.232mm) Weight • 0.6 lb (0.3 kg) Power • Uses AJA power supply model DWP-U-R1, included with purchase • 100-240V, 50/60 Hz Universal input • +5 to 20V DC regulated, 12 watts max Environment •...
  • Page 41: Canadian Ices Statement

    AUSTRIA, BELGIUM, BULGARIA, CYPRUS, CZECH REPUBLIC, DENMARK, ESTONIA, FINLAND, FRANCE, GERMANY, GREECE, HUNGARY, ICELAND, IRELAND, ITALY, LATVIA, LICHTENSTEIN, LITHUANIA, LUXEMBOURG, MALTA, NETHERLANDS, NORWAY, POLAND, PORTUGAL, ROMANIA, SLOVAKIA, SLOVENIA, SPAIN, SWEDEN, SWITZERLAND, UNITED KINGDOM IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0 www.aja.com...
  • Page 42: Korean Kcc Compliance Statement

    As an electromagnetic wave equipment for office use (Class A), (Broadcasting Communication this equipment is intended to use in other than home area. Equipment for Office Use) Sellers or users need to take note of this. IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0 www.aja.com...
  • Page 43: Taiwan Compliance Statement

    Aviso! Leia e siga todos os avisos e instruções assinalados no produto ou incluídos na documentação. Avviso! Leggere e seguire tutti gli avvisi e le istruzioni presenti sul prodotto o inclusi nella documentazione. IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0 www.aja.com...
  • Page 44 (incluindo amplificadores) que produzam calor. Avviso! Non installare vicino a fonti di calore come termosifoni, diffusori di aria calda, stufe o altri apparecchi (amplificatori compresi) che emettono calore IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0 www.aja.com...
  • Page 45 Aviso! Dado que a ficha principal é utilizada como a desconexão para o dispositivo, esta deve manter-se prontamente acessível e funcional. Avviso! Poiché il cavo di alimentazione viene usato come dispositivo di sconnessione, deve rimane prontamente accessibile e operabile. IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0 www.aja.com...
  • Page 46 Aviso! Desconecte este dispositivo da tomada durante trovoadas ou quando não é utilizado durante longos períodos de tempo. Avviso! Utilizzare soltanto i collegamenti e gli accessori specificati e/o venduti dal produttore, quali il treppiedi e l'esoscheletro. IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0 www.aja.com...
  • Page 47 Advertência! Não abra o chassi. Não há internamente nenhuma peça que permita manutenção pelo usuário. Abrir o chassi anula a garantia, a menos que a abertura seja realizada por uma central de serviços da AJA ou por um local autorizado. Avvertenza! Non aprire lo chassis. All’interno non ci sono parti riparabili dall’utente.
  • Page 48 ¡Advertencia! Utilice solamente los accesorios y conexiones especificados y/o vendidos por el fabricante. Aviso! Utilize apenas equipamentos/acessórios especificados e/ou vendidos pelo fabricante. Avviso! Utilizzare soltanto i collegamenti e gli accessori specificati e/o venduti dal produttore. IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0 www.aja.com...
  • Page 49 Index Screen, Web UI 31 Using Web UI Network Screen to Access Media LAN Port Settings Status 23 AJA Support 2 Update Procedure 18 Audio 5 LED Behavior Updating from Web UI 31 Audio Essence Number 27 Ready, Lock and LAN 9...
  • Page 50 Web Browser Accessing Unit Through Its IP Address Accessing User Interface 10 Loading Firmware 12 Preferred 7 System Requirements 7 Web Server Access Password 29 Built In 7, 12, Unit's Internal 7 IP Mini-Converters JPEG 2000 IP Video/Audio Converters v1.0 www.aja.com...
