IPTR-10G2-Series Mini-Converters
SMPTE 2110 IP Tx/Rx
Installation and Operation Guide
Version 2.5r1
Published July 24, 2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPTR-10G2 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for AJA IPTR-10G2 Series

  • Page 1 IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx Installation and Operation Guide Version 2.5r1 Published July 24, 2023...
  • Page 2: Notices

    AJA® and Because it matters.® are registered trademarks of AJA Video Systems, Inc. for use with most AJA products. AJA™ is a trademark of AJA Video Systems, Inc. for use with recorder, router, software and camera products. Because it matters.™ is a trademark of AJA Video Systems, Inc.
  • Page 3: Table Of Contents

    Initial Setup By Web Browser ......16 Initial Setup By AJA eMini-Setup ......16 Hardware Installation .
  • Page 4 Index........72 IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 5: Chapter 1 - Introduction

    Chapter 1 – Introduction Overview AJA IPTR-10G2-Series Mini-Converters are designed for point of use applications for encoding, transport, reception and decoding of IP based video sources. Rugged, compact and fanless, the IPTR-10G2-Series Mini-Converters provide the bridge between Baseband and IP video for a range of applications, such as sending and receiving video over IP from remote facilities in post production, source monitoring, digital signage, and video walls.
  • Page 6: Pre-Built System Configuration Modes For Ipr-10G2

    • Fastest method of moving data through the device (does not require signal processing) • Provides the least amount of packet-level and frame-level protection • Remote sender and AJA IPR-10G2 receiver are locked to PTP PTP Protected • Provides the highest amount of packet-level and frame-level protection, including redundancy support with ST 2022-7 •...
  • Page 7: Iptr-10G2-Series Mini-Converters Features

    • 1x BNC Reference Out, allowing incoming baseband sources to be locked to PTP timing • Frame Sync • 1x mini-USB port for initial network configuration with AJA eMini-Setup software (alternative setup method) IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1...
  • Page 8: Ipt-10G2-Hdmi

    • 1x BNC Reference Out, allowing incoming baseband sources to be locked to PTP timing • Frame Sync • 1x mini-USB port for initial network configuration with AJA eMini-Setup software (alternative setup method) • 5-year international warranty and support IPR-10G2-SDI •...
  • Page 9: Ipr-10G2-Hdmi

    • 1x BNC Reference for analog/tri-level reference input, allowing baseband output to be locked to the facility baseband clock (instead of PTP) • 1x mini-USB port for initial network configuration with AJA eMini-Setup software (alternative setup method) • 5-year international warranty and support IPR-10G2-HDMI •...
  • Page 10: Abbreviated Feature Comparison Chart

    1x 3G-SDI Input/Output HD (up to 60p) Input/Output redundant IP feeds Black Burst/ Tri-level Sync based on PTP Clock 10 GigE Switch Ref Out HD (up to 60p) Redundant IP feeds PTP Generator IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 11 Ready LED Connector Lock LED Link/Act LED 1 Reference Out BNC SFP+ Cage for 10 Gbps Ethernet USB Port SFP+ Cage for 10 Gbps Ethernet +5-16 VDC Link/Act Power Input LED 2 IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 12 Lock LED Connector 2 Link/Act LED 1 Analog/Tri-Level SFP+ Cage for Reference Input BNC 10 Gbps Ethernet USB Port SFP+ Cage for 10 Gbps Ethernet +5-16 VDC Link/Act Power Input LED 2 IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 13 Ready LED Connector Lock LED Link/Act LED 1 Analog/Tri-Level Reference Input BNC SFP+ Cage for 10 Gbps Ethernet USB Port SFP+ Cage for 10 Gbps Ethernet +5-16 VDC Link/Act Power Input LED 2 IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 14: Simplified Block Diagrams And Logic Diagrams

    Video Clock Bypass Packet Protection (ST 2022-7 unsupported) Packet Protection Media LAN 1 (Supporting ST 2022-7 Baseband Framesync when dual SFPs in use) Output Media LAN 2 window size applies here Bypass Framesync IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 15: Frequently Asked Questions

    NOTE: Chrome and Firefox are the preferred web browsers for control on Windows. Safari is the preferred web browser for control on macOS. Other web browsers may work, but AJA cannot guarantee consistent operation for all web browsers or web browser versions.
  • Page 16: Initial Setup By Web Browser

    2. Using the AJA eMini-Setup application running on the host computer that is directly connected to the 10 GigE IP Mini-Converter via USB. Initial Setup By Web Browser NOTE: Chrome and Firefox are the preferred web browsers for control on Windows.
  • Page 17: Hardware Installation

    NOTE: DHCP is enabled by default, and if the device is connected to a DHCP server the IP address field will populate. 6. Enter the IP address into a browser window. The web UI for your AJA device will display.
  • Page 18: Chapter 2 - Emini-Setup

    Subsequently, that device can then be reconfigured over that network, using its IP address and built-in web server. NOTE: The eMini-Setup application is only used to setup selected Ethernet capable AJA devices, and cannot be used to connect to or setup other AJA Mini-Converters.
  • Page 19: Installing Emini-Setup

    When finished, an AJA eMini-Setup shortcut will be installed on the desktop, and you will be able to locate the eMini-Setup application in the AJA folder in the Programs listing. NOTE: If the eMini-Setup application already exists on the PC, a different Setup Wizard appears.
  • Page 20: Mac Installation

    5. To complete the installation drag the “AJA eMini-Setup” icon to the Applications folder. Running eMini-Setup Connect your Ethernet capable AJA device to the PC or Mac via the supplied USB cable, and then connect the external power supply (supplied) to that AJA device. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1...
  • Page 21: Pc Startup

    PC Startup To run eMini-Setup on a PC, double-click on the AJA eMini-Setup icon on your desktop, or open the AJA folder in the program list and click on the AJA eMini- Setup application located inside the eMini-Setup folder. Figure 15. Launching eMini-Setup on a PC...
  • Page 22: Control Lan Tab Screen

    Sn - This is the factory set unique serial number of your AJA device. If you ever call AJA Support for service, you may be asked for this number. A status field at the bottom of the screen shows if the eMini-Setup application is connected and communicating with an AJA device.
  • Page 23: Media Lan 1 Tab Screen

    Figure 18. eMini-Setup Media LAN 1 Tab Screen Use this Media LAN 1 tab to change the corresponding media network setup on the connected AJA device. You must click the Apply button to initiate any network configuration changes. IP Address Type - Choose from DHCP or Static IP Address.
  • Page 24: Media Lan 2 Tab Screen

    Figure 19. eMini-Setup Media LAN 2 Tab Screen Use this Media LAN 2 tab to change the corresponding media network setup on the connected AJA device. You must click the Apply button to initiate any network configuration changes. IP Address Type - Choose from DHCP or Static IP Address.
  • Page 25: Update Tab Screen

    4. Click the Update tab. Click the Browse button. Navigate to the firmware (.ajas extension), open it, and confirm the update. Progress will be shown via the “Progress” bar. 5. After the update, the AJA device must be rebooted by clicking on the Reboot button in the prompt window. See also: "Firmware Screen"...
  • Page 26: Info Tab Screen

    AJA Support for service or technical support. System Name - This field allows you to give your AJA device a unique name. This can be useful if you have several attached to a Mac/PC via USB so you can distinguish between them easily.
  • Page 27: Chapter 3 - Iptr-10G2-Series Mini-Converters Web Interface

    NOTE: Safari is the preferred web browser for control on the Mac, and additionally Chrome and Firefox on Windows. Other web browsers may work, but AJA cannot guarantee consistent operation for all web browsers or web browser versions. To connect to the 10 GigE IP Mini-Converter, attach the unit to your network and enter its Control Network IP address into the web browser.
  • Page 28: Web Browser Via Ethernet

    Ethernet LEDs of that device at a 1 second rate. Parameters and Information The rest of the screen displays all the parameter selections and information available for the selected IP Mini-Converter screen. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 29 • For values with sliders, fine control is achieved using the arrow keys on the keyboard to move the slider the minimum amount. The numeric value can also be clicked on to enter a specific value. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 30: Status Screen

    LLDP, the Chassis ID and the Port ID of the first switch encountered upstream in the path from the IP Mini-Converter device to the network will be displayed in the LLDP Chassis ID and LLDP Port ID fields. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 31: Ipr-10G2-Hdmi

    Figure 24. IPT-10G2-SDI Status Screen 2 of 2 IPR-10G2-HDMI Figure 25. IPR-10G2-HDMI Status Screen 1 of 2 The IPR-10G2-HDMI Status screen reports the current status and settings for: • Input Status • Video Clock Status • Network Status IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 32: Config Screen

    This section describes the Config Screen for the IPT-10G2-SDI followed by the Config Screen for the IPR-10G2-HDMI. IPT-10G2-SDI The IPT-10G2-SDI Config Screen, shown in three parts, has the parameters required for the general operation of the IPT-10G2 units. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 33 Enable or disable network discovery using Universal Plug and Play. IGMP Version Select the Internet Group Management Protocol Version. AJA supports IGMP v2 and v3. NOTE: It is important to know which version of IGMP is in use on your network.
  • Page 34 Enter the destination IP address of the video packets. Video Destination Port 1 Enter the UDP destination port of the video packets. Video Source Port 1 Enter the UDP source port of the video packets. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 35 Enter the UDP destination port of video packets. Video Source Port 2 Enter the UDP source port of the video packets. Audio Dest IP Address 2 Enter the destination IP address of the audio packets. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 36 NOTE: The Ref Output V Offset control is displayed only when the Frame Sync Mode control is set to Bypass. Select the vertical reference offset in pixels (range -1125 lines to +1125 lines). IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 37 2. Click the slider control to select it, then use the left/right or up/down arrow keys on your keyboard, or 3. Click the Milliseconds text to select it, then enter a numerical value using your keyboard. Audio Mute Enable or disable audio mute. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 38 If the unit does not find an NMOS registry, it continues to announce itself through MDNS so that it can be discovered. Once discovered, it registers itself with whatever has discovered the unit through MDNS. Ember+ Enable or disable Ember+ network discovery for the device. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 39: Ipr-10G2-Hdmi

    Enable or disable user password authentication for the web interface. Identify LED Enables flashing of the Ethernet LEDs on the unit. UPnP Host Enable or disable network discovery using Universal Plug and Play. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 40 IGMP Version Select the Internet Group Management Protocol Version. AJA supports IGMP v2 and v3. NOTE: It is important to know which version of IGMP is in use on your network. Selecting the wrong IGMP version may cause long delays in processing multicast subscriptions.
  • Page 41 Unlike the five pre-built System Modes just described, each of which are "safe," the Advanced Mode, described below, does not guard against a user applying contradictory settings that could provide unpredictable results. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 42 PTP Grandmaster, then set this field to the ID of the preferred Grandmaster. Example of a PTP Grandmaster ID: • 08-00-11-FF-FE-22-04-D6 PTP Grand Master Capable NOTE: Applicable only if PTP is selected for Video Output Clock Selection. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 43 Select either of the following options: • Use Audio Src • Bypass Audio Src IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 44 • Audio Channels • Audio Packet Interval • Video Destination Address • Video Source Address • Audio Destination Address • Audio Source Address. • Video 2 Destination Address • Video 2 Source Address IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 45 If the unit does not find an NMOS registry, it continues to announce itself through MDNS so that it can be discovered. Once discovered, it registers itself with whatever has discovered the unit through MDNS. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 46 Color bars with a moving gray line are generated in the currently selected video format and sent to the Video Output. NOTE: The Test Pattern is supported only in 1080p and 1080i formats. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 47 If the unit does not find an NMOS registry, it continues to announce itself through MDNS so that it can be discovered. Once discovered, it registers itself with whatever has discovered the unit through MDNS. Ember+ Enable Enable or disable network discovery for the device. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 48: Presets Screen

    CAUTION: When you recall a Preset Configuration, the recalled preset immediately replaces the system’s existing configuration. All previous settings are lost unless you have previously stored them in another preset configuration or an exported file. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 49: Network Screen

    IMPORTANT: Using the Keyboard Number 0 (zero) will initiate a Factory Reset for the device. Network Screen Use the Network Configuration Control Tab to configure or modify settings for the Control LAN Ethernet port. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 50 Recall Export Import Erase Presets #1- Export Import Erase Use the Network Configuration Media 2 Tab to configure or modify settings for the Media 2 SFP+ cage for 10 Gbps Ethernet port. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 51 Netmask determines the subnet mask to be used for TCP/IP networking. • Enter a subnet mask compatible with your LAN. This is only needed for Static IP configurations. The factory default Subnet Mask is 255.255.255.0 IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 52: Firmware Screen

    The Update Firmware screen allows you to download and install a firmware update from AJA. To Download and Install Updated Firmware 1. Visit the AJA website (aja.com) to locate and download the updated software. The following page provides support information and will include links to locations where you can download updates: https://www.aja.com/family/ip-converters#support...
  • Page 53: Booting The Iptr-10G2-Series Mini-Converters From The Safeboot Firmware

    5. Finally, update the firmware as described above under "Downloading and Installing Updated Firmware" on page 52. Following a successful firmware update and reboot, the message "None" displays under the Alarms heading. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 54 Figure 40. The alarm message after a successful firmware update IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 55: Appendix A - Specifications

    • NMOS discovery and control according to standards IS-04 v1.3 and IS-05 v1.1 • Ember+ control (no discovery, control only) • AJA REST API control (discovery via SSDP or MDNS) • LLDP (Link Layer Discovery Protocol) • Supported over dedicated management Ethernet port and in-band over...
  • Page 56 • Web and REST clients supported for remote network setup and configuration • 1x USB 2.0 Mini-B connector • AJA eMini-Setup supported for network setup and configuration via local desktop computer • Web and REST configuration is also supported in-band over media ports Size (w x d x h) •...
  • Page 57: Ipt-10G2-Hdmi Tech Specs

    • NMOS discovery and control according to standards IS-04 v1.3 and IS-05 v1.1 • Ember+ control (no discovery, control only) • AJA REST API control (discovery via SSDP or MDNS) • LLDP (Link Layer Discovery Protocol) • Supported over dedicated management Ethernet port and in-band over...
  • Page 58: Ipr-10G2-Sdi Tech Specs

    • Web and REST clients supported for remote network setup and configuration • 1x USB 2.0 Mini-B connector • AJA eMini-Setup supported for network setup and configuration via local desktop computer • Web and REST configuration is also supported in-band over media ports Size (w x d x h) •...
  • Page 59 • NMOS discovery and control according to standards IS-04 v1.3 and IS-05 v1.1 • Ember+ control (no discovery, control only) • AJA REST API control (discovery via SSDP or MDNS) • LLDP (Link Layer Discovery Protocol) • Supported over dedicated management Ethernet port and in-band over...
  • Page 60: Ipr-10G2-Hdmi Tech Specs

    • Web and REST clients supported for remote network setup and configuration • 1x USB 2.0 Mini-B connector • AJA eMini-Setup supported for network setup and configuration via local desktop computer • Web and REST configuration is also supported in-band over media ports Size (w x d x h) •...
  • Page 61 • NMOS discovery and control according to standards IS-04 v1.3 and IS-05 v1.1 • Ember+ control (no discovery, control only) • AJA REST API control (discovery via SSDP or MDNS) • LLDP (Link Layer Discovery Protocol) • Supported over dedicated management Ethernet port and in-band over...
  • Page 62 • Web and REST clients supported for remote network setup and configuration • 1x USB 2.0 Mini-B connector • AJA eMini-Setup supported for network setup and configuration via local desktop computer • Web and REST configuration is also supported in-band over media ports Size (w x d x h) •...
  • Page 63: Appendix B - Safety And Compliance

    AUSTRIA, BELGIUM, BULGARIA, CYPRUS, CZECH REPUBLIC, DENMARK, ESTONIA, FINLAND, FRANCE, GERMANY, GREECE, HUNGARY, ICELAND, IRELAND, ITALY, LATVIA, LICHTENSTEIN, LITHUANIA, LUXEMBOURG, MALTA, NETHERLANDS, NORWAY, POLAND, PORTUGAL, ROMANIA, SLOVAKIA, SLOVENIA, SPAIN, SWEDEN, SWITZERLAND, UNITED KINGDOM IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 64 For more information about where you can drop off your waste for recycling, please contact your local authority, or where you purchased your product. Korea KCC Compliance Statement IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 65 Aviso! Leia e siga todos os avisos e instruções assinalados no produto ou incluídos na documentação. Avviso! Leggere e seguire tutti gli avvisi e le istruzioni presenti sul prodotto o inclusi nella documentazione. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 66 (incluindo amplificadores) que produzam calor. Avviso! Non installare vicino a fonti di calore come termosifoni, diffusori di aria calda, stufe o altri apparecchi (amplificatori compresi) che emettono calore IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 67 Aviso! Dado que a ficha principal é utilizada como a desconexão para o dispositivo, esta deve manter-se prontamente acessível e funcional. Avviso! Poiché il cavo di alimentazione viene usato come dispositivo di sconnessione, deve rimane prontamente accessibile e operabile. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 68 Aviso! Desconecte este dispositivo da tomada durante trovoadas ou quando não é utilizado durante longos períodos de tempo. Avviso! Utilizzare soltanto i collegamenti e gli accessori specificati e/o venduti dal produttore, quali il treppiedi e l'esoscheletro. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 69 Advertência! Não abra o chassi. Não há internamente nenhuma peça que permita manutenção pelo usuário. Abrir o chassi anula a garantia, a menos que a abertura seja realizada por uma central de serviços da AJA ou por um local autorizado. Avvertenza! Non aprire lo chassis. All’interno non ci sono parti riparabili dall’utente.
  • Page 70 ¡Advertencia! Utilice solamente los accesorios y conexiones especificados y/o vendidos por el fabricante. Aviso! Utilize apenas equipamentos/acessórios especificados e/ou vendidos pelo fabricante. Avviso! Utilizzare soltanto i collegamenti e gli accessori specificati e/o venduti dal produttore. IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
  • Page 71: Warranty And Liability Information

    AJA Video shall pay to return the product to Customer, but only if to a location within the country in which the AJA Video service center is located. SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OF IMPLIED WARRANTIES OR LIMITATIONS ON APPLICABLE STATUTORY RIGHTS OF A CONSUMER, SO SOME OR ALL OF THE TERMS OF THIS PARAGRAPH MAY NOT APPLY TO YOU.
  • Page 72: Index

    Index Installation 15 Remote Control 27 AJA Support 2 Installation Web Interface 27 Audio eMini-Setup on Mac 20 RCA Analog Audio Output 47 eMini-Setup on Windows 19 Authentication 27 Of Firmware Using eMini-Setup Presets Disabling 26 Overview 15 Changing Name 49...
  • Page 73 Enabling or Disabling for Web Interface Web Browser Accessing Unit Through Its IP Address 18 Loading Firmware 18 Preferred 15 System Requirements 15 Web Server Access Password 49 Built In Unit's Internal 15 workflow diagrams 10 IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 www.aja.com...
