Supported digital measurement calculations:

•
Width (for persistent measurements, this is the time span of the measurement)
•
Frequency (this is just 1/width)
•
Average Frequency (average frequency of all complete cycles inside the range)
•
Average Duty Cycle (average duty cycle of all complete cycles inside the range)
•
Count of Rising Edges
•
Count of Falling Edges
•
Count of Positive Pulses
•
Count of Negative Pulses
•
Minimum Positive Pulse Width
•
Maximum Positive Pulse Width
•
Minimum Negative Pulse Width
•
Maximum Negative Pulse Width
•
Period (for persistent measurements, this is the time span of the measurement)
•
Average Period (average period of each complete cycle in the range)
•
Count of Complete Periods (Cycles)

Supported analog measurement calculations:

•
Width (for persistent measurements, this is the time span of the measurement)
•
Frequency (this is just 1/width)
•
Period (this is the same as the width for persistent measurements)
•
Min-Max Voltage (displays both the minimum voltage and the maximum voltage in a range)
•
Start Voltage (the voltage at the start of the span)
•
End Voltage (the voltage at the end of the span)
•
Delta Voltage (Abs (Start-End))
•
Peak to Peak Voltage (Max-Min)
