- Page 1 INSTALLATION INSTALLATION AND USE MANUAL AND USE MANUAL LB.00193.14. LB.00193.14.EN EDITION January EDITION January 2013 2013 www.carimali.com lb-00193-14.EN Pag. 1 10-02-09...
- Page 2 lb-00193-14.EN Pag. 2 10-02-09...
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION AND GENERAL NOTES ................. 4 INSTALLATION NOTES ..................... 4 USE AND MAINTENANCE NOTES ..................4 MAIN FEATURES ....................... 5 MACHINE KEYPAD ......................7 STARTING UP ........................7 DISPENSING ........................8 HOW TO MAKE A GOOD CUP OF COFFEE ..............8 DOSE PROGRAMMING ...................... -
Page 4: Introduction And General Notes
After unpacking check that the machine is not damaged. If in doubt, do not use the machine and contact an Carimali Spa. Authorised Service Centre. All packing materials (plastic wrapping, polystyrene, nails, etc.) are potentially dangerous and must be kept out of children’s reach and disposed of in a safe manner for the environment. -
Page 5: Main Features
MAIN FEATURES MACHINE PRATICA1 GR. PRATICA 2 GR. PRATICA DOUBLE STEAM 2 GR. Display Maximum quantity of coffee dispensed per hour Width (mm.) Height (mm.) Depth (mm.) Net weight (Kg.) Boiler capacity (lt.) Hot water nozzle Steam nozzle Automatic cappuccino LM maker optional Boiler resistor (W) Standard version 1600 2700... - Page 6 ELECTRIC CONNECTION HYDRAULIC CONNECTION WATER TAP WATER 1 – 6 Bar DRAIN WATER FILTRE WATER FILTRE 0,1-0,6MPa WATER SOFTNER lb-00193-14.EN Pag. 6 10-02-09...
-
Page 7: Machine Keypad
MACHINE KEYPAD PRATICA E KEY 1 KEY 1 KEY 2 KEY 2 KEY 3 KEY 3 KEY 4 KEY 4 KEY 5 KEY 5 Group Group keypad Key 1 Key 1 1 Espresso 2 Espressi Key 2 Key 2 1 Coffee Key 3 Key 3 Key 4... -
Page 8: Dispensing
DISPENSING 1) Coffee Dispensing. Place a cup under the dispenser and press one of the coffee dose keys. In case the machine is electronic version E, the dose will automatically stop once the pre-programmed dose has been delivered. On the contrary, in case of manual version P, press again the key to stop dispensing. -
Page 9: Dose Programming
DOSE PROGRAMMING The following procedure is valid for Pratica E1 and Pratica E2 Pratica E1 and Pratica E2, but note that the display messages are shown only by Pratica E2: the display messages are shown only by Pratica E2: 2 groups with display. 1) Programming the volumetric coffee dose. - Page 10 To exit from the technical program menu press T5 ( Menu ) lb-00193-14.EN Pag. 10 10-02-09...
-
Page 11: Parameters Programming In The Machine Without Display
PROGRAMMING PRE INFUSION - ONLY PRATICA E1 AND PRATICA DOUBLE STEAM Following this procedure it is possible to enable the pre-infusion for buttons no.1 and no.2 of each keyboard. Proceed as follows: Power the machine OFF by means of the switch Power the machine ON by keeping pressed key no.1 until the LED next to continuous key in lighted Power the machine OFF by means of the switch Power the machine ON, which is now ready to be used with pre-infusion enabled. -
Page 12: Washing
WASHING Washing the group and filter holder. It is advisable to carry out these types of washing at the end of each working day. 1a) washing the filter holders. Carry out the following operations: Remove the filters from the filter holders and wash both parts under running water. Remove the remaining coffee using the provided brush ( code N°... - Page 13 MANUAL CLEANING OF STEAM WAND PLEASE NOTE: IT IS ADVISABLE TO CARRY OUT THESE TYPES OF CLEANING AT THE END OF EACH WORKING DAY 1► 2► Leave the steam wand into Clean the steam wand by hot water for 5 minutes. means of a cloth.
-
Page 14: Special Functions For Machine Calibration
SPECIAL FUNCTIONS FOR MACHINE CALIBRATION ONLY ASSISTANCE SERVICE PERSONNEL AUTHORIZED BY I.M.C. SPA. ARE PERMITTED TO ENABLE THE USE OF THESE FUNCTIONS. Calibrating the coffee dispensing pressure ( pump pressure) To calibrate the water pump, remove the drip tray (1) then the front panel (2) and calibrate the pump by turning the adjustment, clockwise to increase the pump pressure or anticlockwise to reduce pressure. - Page 15 Turbine alarm. Cause: the volume meter is not sending signals to the control unit within a time-out of 5 seconds. Result: delivery continues up to a time-out of 240 seconds or until the selected key is pressed, and all the LEDs on the push-button panels flash (medial flashes) Solution: carry out the following controls.
-
Page 16: Suggested Ordinary Maintenance
Temperature probe alarm First case: the temperature inside the boiler has reached the maximum value of 131° C Effect: boiler heating is interrupted and drink keys are disabled. Solution: swicth off the machine ( OFF ), check and if needed replace the “ triac”. Second case: the temperature probe is defective and send a 0 Ohm (short circuit) signal to the pc board. - Page 17 The Carimali product you have purchased is subject to Directive 2002/96/EC of the European Parliament and the Council of the European Union on waste electrical and electronic equipment (WEEE) and, in jurisdictions adopting that Directive, is marked as being put on the market after August 13, 2005, and should not be disposed of as unsorted municipal waste.
