MakerBot Replicator 2X Quick Start Manual page 2

READ OTHER SIDE BEFORE STARTING
1 Open box
4 Install handle
7 Plug in power cable and power supply
Power Cable
10 Turn knobs clockwise to lift platform
13 Load filament into right extruder
16 Check for SD Card
2
5
8
Ensure that
the outlet
is nearby and
easily accessible.
Power Supply
11 Turn knobs counterclockwise to lower platform
14
17
Remove from box
Be careful of gantry.
Add spool holders and guide tubes
Switch on
Remove plastic debris
Choose something to print
3 Clip zip ties and remove gantry clip
6 Add spool to right side
9 Follow directions on LCD panel
12 Wait for the right extruder to heat
15 Add hood
18 Press "M" to print
