E-Plex 1500 Series
Installation Guide
for door thickness 1
3
/
" to 2"
8
PARTS LIST
PARTS LIST
TOOLS REQUIRED
A- Outside Housing Assembly
• Safety Glasses
B- Gasket
•
/
" (13mm) Chisel
1
2
C- Dead Bolt Assembly
•
1
/
" (3mm) Drill Bit
8
D- Inside Trim Assembly
•
/
" (4mm) Drill Bit
5
32
E- 2 X Mounting Screws (12-24 X 1
5
/
")
8
•
1
/
" (13mm) Drill Bit
2
F- 2 X Screws (8-32 X
/
")
7
32
• 1" Drill Bit or Hole Saw
G- Strike Plate
• 2
1
/
" (54mm) Hole Saw
8
H- 4 X Screws (8-32 X
/
")
3
4
• Drill
J- Reinforcing Plate
• Awl or Center Punch
K- Dust Box
• Small Screwdriver (
L- 2 X Wood Screws 3" Long
• Phillips Screwdriver (#2)
M- Tail Piece
• Adjustable Square
N- Inside Cover
• Tape Measure
P- Screw (6-32 X
3
/
", Flat Head)
4
Q- Cylinder Cap
R- Key (may be shipped separately)
S- 3 Batteries "AA"
T- Key Cylinder (may be shipped separately)
U- 2 X Screw (6-32 X
/
", Pan Head)
3
4
V- 1 X Split Lock Washer
1
DOOR PREPARATION
2
3
/
" (60mm) or 2
8
NOTE: Drill from both sides of the door to
prevent unsightly damage.
1. Determine which template fits your
E1500 lock installation, either 2
3
/
"
8
(60mm) or 2
/
" (70mm) backset. See
3
4
note 2 on drilling template
2. Place appropriate template (supplied)
onto door and mark holes.
3. Drill holes as per dimensions on the
Center
Line
template. The 1" (25mm) hole to be on
the center line of door thickness.
2
/
" (54mm)
1
8
Diameter
4. Mortise door edge for dead bolt face
Hole Saw
plate.
4
KEY OVERRIDE CYLINDER – If cylinder is not already assembled in the lock, proceed as follow:
1. Remove 4 screws
3. Install Key Cylinder
2. Remove back plate
5
ADJUST LOCK HANDING ON OUTSIDE HOUSING ASSEMBLY "A"
Right Hand (RH)
Ring
opening far
from slot
Groove at
6:00 o'clock
!
!
WARNING
WARNING
1- Please read and follow all directions carefully.
3- Wear safety glasses when making the holes.
2- Carefully inspect glass, door frame, door etc... to ensure that the
4- All the following operations and testing of the lock to be done with
recommended procedures will not cause damage. Kaba Ilco standard
door open.
warranty does not cover damages caused by installation.
LOCK DIAGRAM
A
R
T
Q
H
1
/
" approx.)
8
M
C
H
D
G F
L
J
K
2
3
INSTALL DEADBOLT IN DOOR
3
/
" (70mm)
2. ADJUST BACKSET
4
OF DEADBOLT
1
2
3
Do not remove tape.
The deadbolt is pre-set
as 2
/
" (70mm) backset.
3
4
1"(25mm)
Proceed as illustrated to
Diameter
change to 2
3
/
" (60mm)
8
Hole Saw
backset, if required.
4. Watch for wires not to be pinched when re-
installing back plate
5. Re-assemble back plate using screws as
shown
Clearance
Left Hand (LH)
Rotate to change
Hold from
from RH to LH
rotating
!
WARNING
ASSEMBLE TAIL PIECE
6
B
E
S
P
Click in place
U
10
INSTALL INSIDE COVER
E
V
N
3
Do not
remove
2
tape
1
13
STATES OF THE LOCK
Slot
Factory Mode
at the
The factory mode is one of three primary states of the E-Plex Lock. The main characteristics of this state are:
bottom
• The E-Plex Lock opens only when the 8-digit default master combination (1-2-3-4-5-6-7-8) is keyed in.
• The visual indication for 'access granted' is green LED flashing once. A high-pitched tone is also generated while the green LED is on.
• The Master User must change the Master Code to be able to exit the factory mode, and switch to the access mode or pushbutton programming mode.
Access Mode
This mode refers to a lock that is operational for user access, and not in factory or Programming Mode.
Pushbutton Programming Mode
The E-Plex lock enters the Pushbutton Programming Mode when the user enters the master combination or one of the manager combinations, preceded and followed by the
character '#' (ex: #12345678#). Once the E-Plex Lock is in the Pushbutton Programming Mode, the Master/Manager can enter one or more command sequences. Each command
sequence ends with a '#' character that acts like an <enter> character. At the very end of all sequences of programming commands, enter one more # to remove the lock from the
Pushbutton Programming Mode to return to normal access mode.
14
SEQUENCE OF OPERATIONS FOR START-UP PROGRAMMING
Override
Switch
What is the recommended sequence of operations?
With the E-Plex Lock in the factory mode.
• Program the Access Code Length (default length is four digits). The access
code field length can only be changed when the lock is not activated (when
still in the factory mode).
• Change factory Master to your own Master Code (always eight digits) to
place lock in access mode.
Put lock in Pushbutton Programming Mode.
• Set the Date / Time
• Program the Lock ID and Unlock time
• Program the Lock for the Duration of Passage Mode (if desired)
• Program the Lock for Tamper Time Settings
• Program the Lock for Buzzer Volume
Groove at
• Add Access Codes as desired
12:00 o'clock
REMOVE
ASSEMBLE OUTSIDE HOUSING
7
8
INSIDE COVER
Remove tape
11
INSTALL STRIKE ON WOOD FRAME
12
Note:
For maximum
security install
Door
reinforcing plate
stop
Install in door stop side
15
GENERAL PROCEDURE FOR PUSHBUTTON PROGRAMMING
a. Put the lock in Programming Mode by pressing # Master Code #
b. Use the Summary of Commands Table (Section 16) of this guide to enter the
three digit command sequence (Command Type + Function Code), followed by #.
c. Enter the appropriate numbers as required.
d. Press # to end Programming Mode.
e. Once the lock is in programming mode, multiple command sequences can be
entered without having to repeat the #mastercode#. However, if there is no activity
for 15 seconds at the keypad, the lock will automatically exit from programming mode.
9
INSTALL INSIDE TRIM
ASSEMBLY
IMPORTANT: To be tightened very well
E
U
V
Install:
- U fire rated steel doors
- V under bottom screw E
- Batteries after tightening 2 screws E
INSTALL STRIKE ON STEEL FRAME
LIT1054 0913
