Kaba La Gard MECHANICAL Operating And Changing Instructions

OPERATING AND CHANGING INSTRUCTIONS
OPENING THE LOCK - Use the OPENING Index
Always turn the dial slowly and carefully. If you turn past a number in the
combination while dialing, DO NOT turn the dial backwards. You must re-dial
the entire combination. The lock comes with a factory-set combination on 50,
turn the dial to the LEFT (counterclockwise) four complete turns stopping with
50 lined-up on the OPENING Index on the fourth turn. Turn RIGHT until the dial
stops. The combination lock bolt will retract and the safe may be opened.
NOTE: If you dial past the number where you were supposed to stop,
you cannot reverse the dial to correct. The opening procedure must be
repeated from the beginning.
To open a lock with a SET three number combination, for example, 11-36-22,
use the following procedures:
1. Turn the dial to the LEFT (counterclockwise) at least four complete rotations
to clear the lock to accept the combination. Never spin the dial to clear.
2. Using the OPENING Index, turn the dial LEFT and pass the first number of
the combination, 11, three times and stop exactly on 11 the fourth time.
3. Turn the dial to the RIGHT (clockwise) and pass 36 two times and stop
exactly on 36 the third time.
4. Turn the dial LEFT and pass 22 once and stop exactly on 22 the second time.
5. Turn the dial to the RIGHT. When the lock is open, the dial will stop between
90 and 0.
To lock the combination lock, turn the dial four complete rotations to the LEFT.
© copyright 2007
MECHANICAL
(P/N) 12-230 v6 • 7/08
Group 1, Group 2 and Group 2M Lock
Kaba Mas LLC
Page 1 of 2
