3.5.2 Setting Up a Master Radio

Most wireless networks consist of one Master radio and multiple Repeater radios.
All RLX2-IHx series radios are shipped pre-configured as Repeaters by defult.
Your first task in setting up a new network is to configure one radio as the
network Master. This section describes how to configure basic settings for a
Master radio.
To configure a Master radio
1 Start the IH Browser.
2 Open the Radio Configuration / Diagnostic Utility. See Connecting to the
Radio Configuration Utility (page 44).
Tip: You can display the help topic for any parameter in the dialog box by clicking the parameter
name. The cursor changes shape when you move it over a parameter name with help. There is
also a short description of the cursored control at the bottom of the Radio Configuration /
Diagnostic Utility window.
3 On the B
ASIC
M radio button and then select channel 1 (2412 MH
ASTER
following example.
Page 46 of 227
S tab, in the B
ETTINGS
RLX2-IHx series ♦ 802.11a, b, g, n
W S
ASIC IRELESS ETTINGS
Industrial Hotspots
group, click the
) as shown in the
