switch and fix on the one channel. You will receive a message confirming that this
action is desired, press enter to confirm yes.
To return to dual frequency detection, again press the left
arrow – in this case to add the Aero channel to the currently
fixed LTE channel. Sampling will again revert to once per
second per channel.

Leakage Display Level Indicator

When configured or fixed to one channel detection, the
detector performs a leakage level calculation two times per
second. This sampling is too fast to change the display
indicator for every calculation, therefore peak hold
techniques are utilized.
The Snoop leak display shows the peak level detected
over the previous two seconds.
When no leakage has been detected within the last two
seconds, a dash display is indicated.
Detector Mode – Analog
When Analog detector mode is selected, the unit will
clearly display Analog, such that the user knows which mode
was selected. GPS is not required in this mode. Navigation to
the second band and fixing detection to one frequency is the
same as described in Detector Mode – QAM section of this
manual above.
