only be used if a dual band antenna for each of the selected frequencies is being used.
A screen sample showing dual channel detection is shown to the right. The sampling
rate while operating in dual channel detection mode is once per second for each
channel.
Detection channel displayed on screen
The frequency band, channel number, and channel
frequency currently being displayed on the detector screen is
shown on the second line from the bottom.
Indication of leaks detected at bands other than displayed
When in dual band detection mode, when a leak is
detected at a band other than that displayed on the screen,
feedback is provided through audio alarms as well as
flashing at the bottom of the screen that indicates the bands
in which the leaks were detected.
Switch to different band
To have the display switch to the other frequency band, simply press the right
arrow and the display will be changed.
Fix detection to one frequency
When operating in the dual
channel mode, the user can "Fix"
on one of the frequency bands,
corresponding to that band
currently being displayed. This
action switches to that selected
channel being sampled two times per second. This may be desirable when performing
the final step leakage source identification process. Press the left arrow button to
21
