Signal alarms

To change the alarm value for both the low and LTE
bands, use arrow keys to navigate to the item you would like
to change, press enter and then use the arrow keys to
increase or decrease the number.

SE Test alarms

The Shielding Test alarms also display a shielding
effectiveness indicator, which equates the detected signal to
shielding effectiveness. From this setting, one can see that it
is possible to locate very small leaks which could be the
source of forward ingress from close proximity transmitters
such as LTE devices.
To change the alarm value, navigate to the alarm level
indicator and use the arrows to increase or decrease the
alarm setting.

Calibration

The calibration setting is used to normalize the setup to a
known leak with a known level, and to compensate for
antenna variations, and other internal variations. Calibration
Factors" are factory set for the type of antenna supplied with
each Snoop.
19
