The next step is to select the desire channel or frequencies for the selected
modulation format within the selected band, and then configure for the specifics and
details related to the selected modulation format as described below.
After one frequency band is configured, navigate to the Next band line and press
enter, then repeat the process for the second band. When Auto Detection is enabled,
the QS server will control the detection channel and will over-ride any channel settings
configured on the local detector.

Channel - Analog detection

When Analog detection is selected, in addition to the
channel configuration, an option to use analog tagging is
available. From the Low band line, press enter, then use the
arrow keys to select Analog.
Analog detection option is not available as a selection
option for the LTE band.

Analog channel

To select the channel, navigate to the Channel line, press
enter, and then use the right and left arrow keys to select the
desired channel.
If the channels displayed are different from the television
standard utilized in your network, go to the General settings
page, select Standard, and change to the appropriate desired television standard.

Tag confirmation on/off

If utilizing an existing AM tagging system is desired, then
the TAG confirm option needs to be set to ON. Navigate to
the TAG confirm line, press enter, use the arrow keys to
toggle ON/OFF.
