EtherNet/IP - General info

2.
E
N
THER
EtherNet/IP is industrial Ethernet network solution available for manufacturing automation. Ether-
TM
Net/IP
is a trademark of ODVA, Inc.
CIP™ (Common Industrial Protocol) encompasses a comprehensive suite of messages and services
for a variety of manufacturing automation applications, including control, safety, synchronization,
motion, configuration and information. CIP provides users with unified communication architecture
throughout the manufacturing enterprise.
More information on EtherNet/IP can be found at www.odva.org
Table 2. List of abbreviations used in this document
Abbreviation
CIP
STP
DHCP
FB
GW
PLC
PDI
PDO
RPM
ACD
ARP
LED
TCP/IP
UDP
EDS
RPI
MAC
DNS
TTL
2.1

Connections and Wiring

The VACON® 100 Family AC drives support 10/100Mb speeds in both Full and Half-duplex modes.
The drive must be connected to the Ethernet network with a shielded CAT-5e cable. Use a so called
crossover cable (at least CAT-5e cable with STP, Shielded Twisted Pair) if you want to connect the
drive directly to the master appliance.
Use only industrial standard components in the network and avoid complex structures to minimize
the length of response time and the amount of incorrect dispatches.
24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com
/IP - G
ET
ENERAL INFO
Common Industrial Protocol
Shielded Twisted Pair
Dynamic Host Configuration Protocol is used for
dynamical resolving of network configuration parame-
ters like an IP address.
Fieldbus
Gateway
Programmable Logic Controller
Process Data In
Process Data Out
Revolutions per minute
Address Conflict Detection
Address Resolution Protocol
Light-Emitting Diode
Transmission Control Protocol / Internet Protocol
User Datagram Protocol
Electronic Data Sheet
Requested Packet Interval
Media Access Control
Domain Name System
Time To Live
Explanation
vacon • 6
2
