Ethernet installation
3.
E
THERNET INSTALLATION
3.1
Installation in VACON
1
Open the cover of the AC drive.
The relay outputs and other I/O-terminals may have a dangerous control voltage
present even when the AC drive is disconnected from mains.
Locate the components that you will need on the AC drive to connect and run the
2
Ethernet cables.
Be sure not to plug the Ethernet cable to the terminal under the keypad! This
might harm your personal computer.
13006.emf
24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com
100 INDUSTRIAL and FLOW
®
M4x55
Figure 1.
vacon • 8
9174.emf
3
