Wire sensors to the I/O interface

To wire third-party sensors to the Connect Sensor I/O interface, you need the following equipment:
A slot-headed 0.4 x 2.5 x 80 mm screwdriver
n
Wire size 1.29-0.25 mm (16-30 AWG) for each pin connector
n
Note All external or field wiring must be in accordance with NFPA 70 Article 501.10(B).
To wire sensors to the I/O interface:
1. Open the Connect Sensor enclosure and disconnect all power sources.
Digi Connect® Sensor I/O Wiring Guide
CAUTION! You must disconnect power from Connect Sensor before wiring
sensors to the I/O interface.
