I/O interface pin assignments
Pin number
7
8
9
10
11
12
Digi Connect® Sensor I/O Wiring Guide
Assignment
A2 GND
A2 IN
A2 Pwr
A1 GND
A1 IN
A1 Pwr
Signal
Analog interface 2, ground
Analog interface 2, analog input
Analog interface 2, power output
Analog interface 1, ground
Analog interface 1, analog input
Analog interface 1, power output
12-pin connector details
9
