6.2 Expansion Header
On the left hand side of the board is a female expansion header to connect to a Silicon Labs EFM8 or EFM32 Starter Kit (STK). The
connecter contains a number of output and communication pins that can be used to communicate with the MCU on the STK. The re-
sults from the touch qualification engine are routed out to these pins. Additionally, the VMCU, 3V3, and 5V power rails are also impor-
ted. The figure below shows the pin assignment of the expansion header.
The CPT007B SLEXP8007A outputs using GPIO.
The pin assignment of the expansion header and the peripheral function are listed below in the figure and table.
CPT007B pin
OUT00
OUT01
OUT02
OUT03
OUT04
OUT05
OUT06
silabs.com | Smart. Connected. Energy-friendly.
OUT03
NC
NC
OUT06
OUT05
OUT04
NC
CPT Pin
Figure 6.2. Expansion Header
Table 6.1. Pins available on Expansion Header
EXP Header pin number
6
10
16
15
5
7
9
UG132: CPT007B SLEXP8007A Kit User's Guide
OUT02
NC
NC
OUT01
NC
OUT00
NC
Connectors
