1. Before Using the Product
This chapter provides information you should know before using the product.
About the Board
This board is a PCI bus interface board for performing RS-232C serial communications with external
devices.
The <GCOM-2C2-PCI> has two serial ports per board.
The <GCOM-4C2-PCI> has four serial ports per board.
The <GCOM-8C2-PCI> has eight serial ports per board.
You can use the standard COM driver software (DRV-PAC(W32)) supplied with the board to access the
serial ports as standard Windows COM ports.
Features
-
Maximum communication speed = 921,600bps.
-
The baud rate can be set independently for each channel, by software.
-
Each channel is equipped with separate 128-byte FIFO buffers for transmit and receive.
-
A maximum of 16 boards can be installed as configured in the range COM1 - COM256.
-
Driver software is supplied to allow the serial ports to be used as standard Windows COM ports.
-
The boards use the same easy-to-use 9-pin D-SUB connectors as are used on a PC.
GCOM-2C2-PCI, GCOM-4C2-PCI, GCOM-8C2-PCI
1. Before Using the Product
1
